Underside Panel

The following elements can be found on the underside panel:
The following table contains details on the significant elements on the underside panel.
Item Descripción
A SIM tray for the 3G internal module. It's accessed from the underside of the
router.
B Platform where the label containing the information on the product is placed.
This label contains information on the device model, mac, serial number, etc.
C Slots for wall mount.
