Chapter 3

Install Fittings in the SmarTrax Valve

Before mounting the SmarTrax valve (P/N 334-0003-088) on the machine, install the proper fittings in the
valve. This prepares the valve for installation and simplifies the hose connection process later in the procedure.
Fitting - -4 SAE O-Ring Internal Hex Plug
Fitting - -4 ORFS (M) to -6 SAE O-Ring (M) Straight Adapter
Fitting - -6 ORFS (M) to -8 SAE O-Ring (M) Straight Adapter
Fitting - -8 ORFS (M) to -8 SAE O-Ring (M) 90° Elbow
Fitting - -6 ORFS (M) to -10 SAE O-Ring (M) Straight Adapter
Fitting - -6 ORFS M/F 90° Swivel Elbow Fitting
Fitting - -6 ORFS M/M/F Swivel Run Tee Adapter
12 Case IH 2X44, 2X66, 2X77, and 2X88 Series Combines SmarTrax™ Installation Manual
The appearance of the SmarTrax hydraulic
valve may vary slightly from the images
contained in this manual. However, the fittings,
hose connections, and cable connections
remain the same.
Fitting
NOTICE
Part Number
333-0012-051
333-0012-195
333-0012-199
333-0012-229
333-0012-233
333-0012-065
333-0012-069
Port
PS
LSPV,
LS STEER
P
T
A, B
A
A
