Raven SmarTrax Installation Manual page 14

Case ih 2x44, 2x66, 2x77, and 2x88 series combines

Hide thumbs Also See for SmarTrax:

Table of Contents

Chapter 2

Node Mounting Kit (P/N 117-5030-005)

TABLE 3.


Not Pictured

Note:

The node installation kit is sold separately.

Case IH 2X44, 2X66, 2X77, and 2X88 Series Combines SmarTrax™ Installation Manual

Item Description

Manual - SmarTrax and SmartSteer

Calibration & Operation

Node - SmarTrax 3D CAN Control

Harness - SmarTrax Node

Assembly - SmarTrax Enable Foot Switch

Part Number

Qty.

016-0171-277

063-0173-228

115-4001-109

063-0172-470
