Raven SmarTrax Installation Manual page 10

Chapter 2
SmarTrax Installation Kit (P/N 117-5032-023)
TABLE 1.
6 Case IH 2X44, 2X66, 2X77, and 2X88 Series Combines SmarTrax™ Installation Manual
Item Description
Bracket - Wheel Angle Sensor (WAS) Rod
Mounting
Bracket - Valve Mounting
Bracket - Cruizer Mounting
Bracket - Spacer
Bracket - WAS T-Shaped Mounting
Cable - Bulkhead Adapter
Cable - Valve Harness
Sensor - 250 mm Non-Contact Linear Wheel
Angle Sensor
Mount - M10 Ball Linear Sensor
Clamp - 1-1/4" U-Bolt Muffler
Spacer - 0.406" ID x 0.75" OD x 1" Long
Part Number Qty.
107-0172-030
107-0172-174
107-0172-180
107-0172-182
107-0172-206
115-4001-176
115-4001-177
063-0181-021
103-0001-029
435-3003-056
107-0172-038
1
1
1
1
1
1
1
1
2
2
1
