Raven SmarTrax Installation Manual page 12

Chapter 2
SmarTrax Installation Kit (P/N 117-5032-023)
TABLE 1.
Hydraulic Installation Kit (P/N 117-0199-127)
TABLE 2.
8 Case IH 2X44, 2X66, 2X77, and 2X88 Series Combines SmarTrax™ Installation Manual
Item Description
Washer - 5/16" Lock
Washer - 0.344" ID Flat
Item Description
Fitting - -4 ORFS M/F 90° Swivel Elbow
Fitting - -8 ORFS M/M/F Swivel Run Tee
Adapter
Fitting - -4 SAE O-Ring Internal Hex Plug
Fitting - -6 ORFS M/F 90° Swivel Elbow
Fitting - -8 ORFS M/F 90° Elbow
Fitting - -6 ORFS M/M/F Swivel Run Tee
Adapter
Fitting - -6 ORFS (M) to -6 SAE O-Ring (M)
Straight Adapter
Fitting - -4 ORFS (M) to -6 SAE O-Ring (M)
Straight Adapter
Part Number Qty.
313-1000-019
313-2300-012
Part Number Qty.
333-0012-023
333-0012-028
333-0012-051
333-0012-065
333-0012-067
333-0012-069
333-0012-084
333-0012-195
4
8
2
2
1
2
2
2
2
2
