Features

• STM32L562QEI6QU microcontroller featuring 512 Kbytes of Flash memory and 256 Kbytes of SRAM in
BGA132 package
• 1.54" 240 × 240 pixel-262K color TFT LCD module with parallel interface and touch-control panel
• USB Type-C
• On-board energy meter: 300 nA to 150 mA measurement range with a dedicated USB interface
• SAI Audio CODEC
• MEMS digital microphones
• 512-Mbit Octal-SPI Flash memory
• Bluetooth
• iNEMO 3D accelerometer and 3D gyroscope
• 2 user LEDs
• User and reset push-buttons
• Board connectors:
– USB Type-C
– microSD
– Stereo headset jack including analog microphone input
– JTAG debugger
– DPM dynamic-power measurement interface for external device
– STMod+ expansion connector with fan-out expansion board for Wi‑Fi
compatible connectors
– Pmod
– Audio MEMS daughterboard expansion connector
– ARDUINO
• Flexible power-supply options: ST-LINK, USB V
• On-board STLINK-V3E debugger/programmer with USB re-enumeration capability: mass storage, Virtual
COM port, and debug port
• Comprehensive free software libraries and examples available with the
• Support of a wide choice of Integrated Development Environments (IDEs) including IAR
STM32CubeIDE
Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
UM2617 - Rev 2
™
Sink device FS
®
V4.1 Low Energy module
™
™
card
™
expansion connector
®
Uno V3 expansion connector
®
, Grove and mikroBUS
or external sources
BUS
STM32CubeL5
UM2617
Features
™
MCU Package
™ ®
, Keil , and
