ST STM32L562E-DK User Manual page 50

BGA
pinout
G12
H1
H2
H3
H4
H9
H10
H11
H12
J1
J2
J3
J4
J5
J6
J7
J8
J9
J10
J11
J12
K1
K2
K3
K4
K5
K6
K7
K8
K9
K10
K11
K12
L1
L2
L3
L4
L5
L6
UM2617 - Rev 2
Pin name
PG5
VSSA
PC0
OPAM1_VINM
VSS
VSS
PD14
PD13
PD15
VREFP
PA0
PC5
VDD
PF14
PE8
PE10
PE12
VDD
PD9
PD11
PD12
VDDA
PA2
PA7
PB2
PF11
PG1
PE7
PE14
PB10
PB13
PB14
PB15
PA3
PA6
PA4
PB1
PF12
PF15
Main function
pinout assignment
SPI1.BLE_CS
POWER / GND
OCTOSPI.IO7
-
POWER / GND
POWER / GND
LCD.FMC_D0
ARD.D5_TIM
LCD.FMC_D1
POWER / VREFP
ARD_ADC.A0
ARD_ADC.A5
POWER / VDD_MCU
LCD.RST
LCD.FMC_D5
LCD.FMC_D7
LCD.FMC_D9
POWER / VDD_MCU
LCD.FMC_D14
ARD.D2_IO
ARD.D3_TIM
POWER / VDDA
OCTOSPI.NCS
OCTOSPI.IO2
OCTOSPI.DQS
-
AUDIO_RESETN
LCD.FMC_D4
LCD.FMC_D11
ARD.D0_RX
-
USB_C.FLT
USB_C.CC2
OCTOSPI.CLK
OCTOSPI.IO3
ARD_ADC.A2
OCTOSPI.IO0
-
LCD.CTP_RST
UM2617
STM32L562E-DK I/O assignment
Optional function
pinout assignment
-
-
-
-
-
-
-
-
-
-
STMod+ 13_ADC
-
-
-
-
-
-
-
-
-
-
-
-
-
-
STMod+ SEL_12
-
-
-
T.VCP_RX
STMod+ 1_UART_CTS / STMod+
1_SPI_CSN
-
-
-
-
USB_C.VBUS_VSENSE
-
STMod+ SEL_34
-
page 50/61
