BGA
pinout
L7
L8
L9
L10
L11
L12
M1
M2
M3
M4
M5
M6
M7
M8
M9
M10
M11
M12
UM2617 - Rev 2
Pin name
PE11
PE15
PB11
VSS_SMPS
PB12
PD8
PA5
OPAM2_VINM
PC4
PB0
PF13
PG0
PE9
PE13
VDD_SMPS
VLX
V15
PD10
Main function
pinout assignment
LCD.FMC_D8
LCD.FMC_D12
ARC.D1_TX
POWER / GND
DFSDM_DATIN1
LCD.FMC_D13
ARD_ADC.A3
-
ARD_ADC.A4
OCTOSPI.IO1
-
ARD.D8_IO
LCD.FMC_D6
LCD.FMC_D10
POWER / VDDSMPS
POWER / VLX
POWER / V15SMPS
LCD.FMC_D15
UM2617
STM32L562E-DK I/O assignment
Optional function
pinout assignment
-
-
T.VCP_TX
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
