UM2124
User manual
Getting started with the six-step firmware library for
STM32 Nucleo boards based on STM32F microcontrollers
Introduction
The six-step (trapezoidal) firmware is an easy-to-use and low requirement brushless scalar software
library for three phase permanent magnet (PMSM) and brushless DC motors (BLDC) developed for
STM32 microcontrollers.
The procedure to configure the six-step firmware library for STM32F microcontrollers and drive a BLDC
motor in both open and closed loop is described in the following sections.
The current control method is based on sensorless mode but it is compatible with hall and encoder
speed sensor modes.
The rotor position is reconstructed by BEMF detection.
The six-step library is written in the C programming language and it is based on STM32Cube library.
The IDE tools supported are IAR Workbench, Keil and AC6. The core of this control algorithm is
embedded inside the X-CUBE-SPN7 and X-CUBE-SPN8 firmware package available on the ST web
site.
A prerequisite for using this library is basic knowledge of the C programming language, three phase
motor drives and power inverter hardware. In-depth knowledge of STM32 functions is only required for
customizing existing modules and for adding new ones for complete application development.
November 2016
DocID029868 Rev 1
1/39
www.st.com
