Table 26. Cn7 Lcd Connector Pinout; Figure 21. Cn7 Lcd Connector Pinout - ST STM32L562E-DK User Manual

Table 26 describes the CN7 LCD interface and connector pinout.
STM32
Function
GND
D15
D13
D11
D9
D7
D5
D3
D1
NOE
RS
LCD_RST
IOVCC
GND
LEDK
UM2617 - Rev 2
Figure 21.
Table 26.
Signal name
pin
- GND
PD10 LCD.FMC_D15
PD8 LCD.FMC_D13
PE14 LCD.FMC_D11
PE12 LCD.FMC_D9
PE10 LCD.FMC_D7
PE8 LCD.FMC_D5
PD1 LCD.FMC_D3
PD15 LCD.FMC_D1
PD4 LCD.FMC_NOE
PF0 LCD.FMC_A0_RS
PF14 LCD.RST
- VDD_LCD
- GND
- LEDK
CN7 LCD connector pinout
CN7 LCD connector pinout
Pin name Pin Pin Pin name
GND 1 2 FMARK
DB15 3 4 DB14
DB13 5 6 DB12
DB11 7 8 DB10
DB9 9 10 DB8
DB7 11 12 DB6
DB5 13 14 DB4
DB3 15 16 DB2
DB1 17 18 DB0
RDn 19 20 WRn
RS 21 22 CS
RESET 23 24 IM
IOVCC 25 26 VCI
GND 27 28 LEDA
LEDK 29 - -
UM2617
STM32
Signal name Function
pin
LCD.TE PA8
LCD.FMC_D14 PD9
LCD.FMC_D12 PE15
LCD.FMC_D10 PE13
LCD.FMC_D8 PE11
LCD.FMC_D6 PE9
LCD.FMC_D4 PE7
LCD.FMC_D2 PD0
LCD.FMC_D0 PD14
LCD.FMC_NWE PD5
LCD.FMC_CS PD7
IM -
3V3_LCD -
LEDA -
- -
TFT LCD
LCD.TE
D14
D12
D10
D8
D6
D4
D2
D0
NWE
CS
IM
VCI
LEDA
-
page 33/61
