STM32 pin
-
PA15
PA12
PA11
-
-
-
-
-
6.8.6
I/O restriction to other features
Caution:
Due to the sharing of some I/Os of STM32L562QEI6QU by multiple peripherals, the following limitations apply in
using the USB features:
The USB UCPD cannot be operated simultaneously with full JTAG (JTDI).
•
If PA15 is used as USB_CC1 (USB peripheral), JTDI cannot be used for JTAG peripheral.
The USB UCPD imposes some restrictions to the ARDUINO
•
If PB5 is used as USB_DBn (USB peripheral) and JP5 is OFF, ARDUINO
be used, and STMod+ SPI3_MOSIP cannot be used.
6.9
microSD™ card
6.9.1
Description
The CN1 slot for the microSD
with SD Memory Card Specification Version 4.1: SDR104 SDMMC_CK speed limited to the maximum allowed I/O
speed. UHS-II mode is not supported.
6.9.2
Operating voltage
The SD card interface is only compatible with the 3.3 V voltage range, from 2.7 to 3.6 V.
The SD card interface does not support the MCU low voltage 1.8 V range.
6.9.3
SD card interface
The SD card interface is used in 4 data lines D [0:3], one CLK, one CDM, and a card detection signal.
Table 18
describes the HW configuration for the SDIO interface.
I/O
PF2
PC8
PC9
PC10
UM2617 - Rev 2
Signal name
Pin
VBUSc
A4
CC1
A5
D+
A6
D-
A7
SBU1
A8
VBUSc
A9
RX2-
A10
RX2+
A11
GND
A12
™
card is routed to the STM32L562QEI6QU SDIO port. This interface is compliant
Table 18.
I/O configuration for the SDIO interface
PF2 is connected to SDCARD DETECT.
PC8 is connected to SDCARD SDIO_D0.
PC8 is shared with STMod+ pin 14 (Timer function).
PC9 is connected to SDCARD SDIO_D1.
™
PC9 is shared with Pmod
pin 8 / STMod+ pin 12 (RST function).
PC10 is connected to SDCARD SDIO_D2.
™
PC10 is shared with Pmod
pin 2 / STMod+ pin 2 (UART_TX function).
Pin
Signal name
B9
VBUSc
B8
SBU2
B7
D-
B6
D+
B5
CC2
B4
VBUSc
B3
TX2-
B2
TX2+
B1
GND
®
and the STMod+.
®
D11 (SPI_MOSI or timer) cannot
Configuration
UM2617
microSD™ card
STM32 pin
-
-
PA11
PA12
PB15
-
-
-
-
page 27/61
