Figure 22 shows the CN14 touch panel connector pinout.
Table 27 describes the CN14 touch panel interface and connector pinout.
STM32
Function
GND
CTP_INT
GND
I2C1_SDA
I2C1_SCL
6.16 Pmod™ connector
6.16.1

Description

The CN4 Pmod
application. The Pmod
6.16.2

Operating voltage

™
The Pmod module is directly supplied by 3.3 V. VDD and VDD_MCU must be set to 3.3 V to be I/O compatible
with the Pmod
6.16.3 Pmod™ interface
A quad SPDT switch driven by two I/Os is used to connect three different interfaces: SPI, UART, and mikroBUS™
interfaces to the Pmod
Table 28 describes the I/O configuration to select the SPI, the UART or the mikroBUS™ interface on PMO
connector.
UM2617 - Rev 2
Figure 22. CN14 LCD touch panel connector pinout
Table 27.
Signal name Pin name
pin
- GND
PF1 LCD.CTP_INT
- GND
PB7 I2C1_SDA
PB6 I2C1_SCL
™
standard connector is in the STM32L562E-DK board to support flexibility in small form factor
™
connector implements the Pmod
™
module.
™
connector.
CN14 touch panel connector pinout
Pin Pin Pin name
GND 1 10 GND
INT 2 9 VDD
GND 3 8 IOVCC
SDA 4 7 RESET
SCL 5 6 GND
™
type 2A and 4A on the STM32L562E-DK board.
UM2617
Pmod™ connector
STM32
Signal name
pin
GND -
VDD_LCD -
VDD_LCD -
LCD.CTP_RST PF15 LCD.RST
GND -
Function
GND
VDD
IOVCC
GND
