Features

• STM32MP135FAF7 MPU with an Arm
• ST PMIC
• 4-Gbit DDR3L, 16 bits, 533 MHz
• 4.3" 480×272 pixels LCD display module with capacitive touch panel and RGB interface
• UXGA 2-megapixel CMOS camera module (included) with MIPI CSI-2
®
• Wi‑Fi 802.11b/g/n
• Bluetooth
• Dual 10/100 Mbit/s Ethernet (RMII) compliant with IEEE-802.3u, one with Wake on LAN (WoL) support
• USB Host 4-port hub
• USB Type-C
• 4 user LEDs
• 4 push-buttons (2× user, tamper, and reset)
• 1 wake-up button
• Board connectors:
– Dual-lane MIPI CSI-2
– 2× Ethernet RJ45
– 4× USB Type-A
– USB Micro-B
– USB Type-C
– microSD
– GPIO expansion
– 5 V / 3 A USB Type-C
– VBAT for power backup
• On-board current measurement
• On-board STLINK-V3E debugger/programmer with USB re-enumeration capability: mass storage, Virtual
COM port, and debug port
• Full mainline open-source Linux
software and examples
• Support of several Integrated Development Environments (IDEs) including STM32CubeIDE
• Bare metal support for RTOS (Microsoft
Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
UM2993 - Rev 2
STPMIC1
®
Low Energy 4.1
®
DRP based on an STM32G0 device
®
camera module expansion
®
™
card holder
®
power supply input (charger not provided)
®
STM32 MPU OpenSTLinux Distribution (such as STM32MP1Starter)
‑A7 32-bit processor at 1 GHz, in a TFBGA320 package
® ®
Cortex
® ®
Azure )
UM2993
®
/ SMIA CCP2 deserializer
Features
