Table 28. I/O Configuration For The Pmod™ Interface; Table 29. Cn4 Pmod ™ Connector Pinout; Figure 23. Cn4 Pmod ™ Connector Pinout - ST STM32L562E-DK User Manual

I/O PF12
STMod+
SEL_34
0
0
1
1
1. The default configuration is shown in bold.
Figure 23 shows the Pmod
Table 29 describes the Pmod
STM32
Function
SPI3
USART3
SPI3
USART3
SPI3
USART3
SPI3
USART3
GND
Power
UM2617 - Rev 2
Table 28. I/O configuration for the Pmod™ interface
I/O PF11
STMod+
SEL_12
0 SPI interface PB13/PB5/PB4/PG9 used for SPI mode
1 mikroBUS™ interface PC10/PC11 for UART mode and PB13/PG9 for SPI mode
0 Not used
1 UART interface PB13/PC10/PC11/PD2 used for UART mode
™
connector pinout.
Figure 23.
™
interface and connector pinout.
Table 29.
Signal name Pin name
pin
PB13 SPI_NSS
PB13 UART_CTS
PB5 SPI_MOSI
PC10 UART_TX
PB4 SPI_MISO
PC11 UART_RX
PG9 SPI_SCK
PD2 UART_RTS
- GND
- VDD
Configuration
™
CN4 Pmod connector pinout
™
CN4 Pmod connector pinout
Pin Pin Pin name
1 1 7 7
2 2 8 8
3 3 9 9
4 4 10 10
5 5 11 11
6 6 12 12
UM2617
Pmod™ connector
(1)
STM32
Signal name Function
pin
PMOD_INT PF5
PMOD_RST PC9
NC NC
NC NC
GND -
VDD -
INT5
Reset
NC
NC
GND
Power
page 35/61
