Table 14 describes the I/O configuration for the Audio DFSDM interface.
JP1 jumper
OFF
OFF
ON
1. The default configuration is shown in bold.
6.7.7

I/O restriction to other features

Caution: Due to the sharing of some I/Os of STM32L562QEI6QU by multiple peripherals, and because
STM32L562QEI6QU only supports one DFSDM interface, the following limitations apply in using the Audio
DFSDM features:
The U16 onboard MEMS, the MEMS module on CN2 and the STMod+ DFSDM interface cannot be operated
simultaneously.
6.8 USB Type-C™ FS port
6.8.1

Description

The STM32L562E-DK Discovery kit supports USB full-speed (FS) communication. The CN15 USB connector is a
™
USB Type-C
The STM32L562E-DK Discovery kit supports USB Type-C
A green LED LD2 lits up when V
a USB device.
6.8.2

Operating voltage

The STM32L562E-DK Discovery kit supports USB voltage, from 4.75 to 5.25 V.
MCU VDD_USB only supports the 3.3 V voltage.
6.8.3

USB FS device

When a USB host connection to the CN15 USB Type-C
STM32L562E-DK Discovery kit starts behaving as a USB device. Depending on the powering capability of the
USB host, the board can take power from the V
corresponding power voltage line is called 5V_UCPD.
Section 6.3 Power supply
Table 15 describes the HW configuration for the USB interface.
I/O
PA11
PA12
6.8.4

UCPD

™
USB Type-C
battery and the SINK mode.
UM2617 - Rev 2
Table 14. I/O configuration for the Audio DFSDM interface
MEMS module STMod+ shield
on CN2 on CN3
NOT NOT
CONNECTED CONNECTED
NOT
CONNECTED
CONNECTED
NOT
CONNECTED
CONNECTED
connector.
is powered by a USB host when the STM32L562E-DK Discovery kit works as
BUS
provides information on how to use the powering option.
Table 15. I/O configuration for the USB interface
PA11 used as USB_FS_N diff pair interface
PA12 used as USB_FS_P diff pair interface
introduces the USB Power Delivery feature. The STM32L562E-DK Discovery kit supports the dead
Configuration
The U2 switch connects directly the DFSDM interface to the U16
onboard MEMS (signal DETECTn low).
The U2 switch disconnects DFSDM of the U16 onboard MEMS, and
connects the DFSDM to the CN2 connector (signal DETECTn switched
HIGH by the module on CN2 pin10).
The U2 switch disconnects DFSDM of the U16 onboard MEMS, and
connects the DFSDM to the CN2 connector (signal DETECTn switched
HIGH by the jumper JP1).
™
sink mode only.
™
connector of STM32L562E-DK is detected, the
terminal of CN15. In the board schematic diagrams, the
BUS
Configuration
UM2617
USB Type-C™ FS port
(1)
