ST STM32L562E-DK User Manual page 32

I/O
PD5
PD4
PF0
PD14
PD15
PD0
PD1
PE7
PE8
PE9
PE10
PE11
PE12
PE13
PE14
PE15
PD8
PD9
PD10
PE1
PF1
PA8
PF14
PF15
PH0
PB6
PB7
Figure 21 shows the CN7 LCD connector pinout.
UM2617 - Rev 2
PD5 is used as LCD.FMC_NWE.
PD4 is used as LCD.FMC_NOE.
PF0 is used as LCD.FMC_A0_RS.
PD14 is used as LCD.FMC_D0.
PD15 is used as LCD.FMC_D1.
PD0 is used as LCD.FMC_D2.
PD1 is used as LCD.FMC_D3.
PE7 is used as LCD.FMC_D4.
PE8 is used as LCD.FMC_D5.
PE9 is used as LCD.FMC_D6.
PE10 is used as LCD.FMC_D7.
PE11 is used as LCD.FMC_D8.
PE12 is used as LCD.FMC_D9.
PE13 is used as LCD.FMC_D10.
PE14 is used as LCD.FMC_D11.
PE15 is used as LCD.FMC_D12.
PD8 is used as LCD.FMC_D13.
PD9 is used as LCD.FMC_D14.
PD10 is used as LCD.FMC_D15.
PE1 is used as LCD_BL_CTRL.
PF1 is used as LCD.CTP_INT for the touch panel.
PA8 is used as LCD.TE.
PF14 is used as LCD.RST.
PF15 is used as CTP.RST.
PH0 is used to switch OFF the LCD power supplies.
PB6 is used as I2C1_SCL shared between ARDUINO
PB7 is used as I2C1_SDA shared between ARDUINO
Configuration
®
, Audio, STMod+, 3D ACC & 3D GYRO.
®
, Audio, STMod+, 3D ACC & 3D GYRO.
UM2617
TFT LCD
