Using the Advanced Image Enhancer dialog box

When you click on any of the Image Enhancement buttons in the Settings
window, the Advanced Image Enhancer (AIE) dialog box appears. In this box,
you can do the following:
1 Select the scan job and image to which image enhancement controls will be applied.
A scan job is a task that you designate the scanner to scan and process, and the
scan job in the AIE dialog box corresponds to the scan job in the Scan Job window.
If you have multiple scan jobs open, you can switch among these jobs and see the
image to be processed.
2 See a thumbnail of the image captured by your scanner, and see how the image
changes when adjustments are applied to it. The "before" and "after" images are the
left and right thumbnails (2a and 2b) in the dialog box.
3 Select another image enhancement tool by clicking on any of the buttons displayed
in the vertical toolbar on the right side of the dialog box.
4 Click on an action button to achieve a particular effect. These buttons are on the
upper right side of the dialog box.
• Click OK to accept changes you have made and to close the AIE dialog box.
• Click Cancel to abandon all changes and to close the AIE dialog box.
• Click Reset to restore settings to default. When you do this, the Reset dialog box
appears, allowing you to reset your settings.
• Click Revert to cancel out the effects of the currently used tool. If you have used
three tools, for instance, Revert will preserve the changes of the first two tools
and ignore the changes made by the third.
Click here to use
3
another image-
enhancement tool
The image
2a
before
enhancements
are applied
4-12 Microtek User's Guide for Windows
Choose your scan
1
job here
Click on a button for
4
an action
See changes to the
2b
image with your
enhancements
