Components of the ScanMaker 45t

The following items are included with your scanner package: a
standard film holder, a glass film holder, several film mounts, and
adhesive strips.
See illustrations below and check to see that you have all of the
items.
Standard film holder
Film mount #1 (60 mm x 60 mm)
35 mm metal slide spacer
Item
Glass film holder
Vinyl strips
Standard film holder
Film mount #1
Film mount #2
Film mount #3
35 mm slide mount
35 mm slide spacer
Magnetic strips
Glass film holder
Film mount #2 (60 mm x 70 mm)
35 mm slide mount Magnetic strips (2)
Qty Purpose
1 To scan irregularly sized film up to 5" x 5"
4 To secure film to the glass film holder
1 To scan standard sized film 60 mm x 60 mm
1 To hold 60 mm x 60 mm film
1 To hold 60 mm x 70 mm film
1 To hold 35 mm x 35 mm film
1 To enclose unmounted 35 mm slides
1 To raise the thickness of mounted 35 mm
slides so that slides can fit on film mount #3.
2 To secure film to the standard film holder

Operating the scanner...

Film mount #3 (for 35 mm slides)
Vinyl strips (4)
