The Preview Window

Elements of the Preview window

1
2
6
1 The Menu Bar includes the
different menus for setting up the
scanner (Scanner menu),
controlling view options (View
menu), customizing the software
(Preferences menu), and
accessing online help (Help
menu).
2 The Tool buttons simplify the
performance of certain tasks.
The Tool buttons are (left to right)
Zoom Preview, Scan Frame,
Magnifying Lens, Hand, and
Color Picker.
3 The Action buttons generate a
specific action from the scanning
software. The Action buttons
include Preview and Scan.
5-4 Microtek User's Guide for Windows
The Preview window is the most prominent
window of the four major windows, and it
includes the various commands and tools for
controlling the scanner.
4 The Scan Material Status
icon shows your scan
material, whether it's
reflective, positive, or
negative.
5 The Preview Area is where
the preview image appears
after you click on the
Preview button.
6 Rulers are located on both
sides of the window to help
you with measurement and
alignment. The ruler unit
can be selected by clicking
on the arrow at the 0,0
point of the rulers.
3
4
5
