Color Picker tool
(Set Shadow and Highlight)
Usage
To sample color from
an area and desig-
nate new shadow or
highlight points.
To select a new shadow or
highlight point:
1 Click on the Color Picker
tool. Then click on the
Window Expansion
button in the Settings
window to see the
bottom half of the
window.
2 Select a color channel in
the Channel box.
3 To select a new shadow
point, click on a pixel in
the preview image that
will serve as the new
shadow point.
To select a new highlight
point, hold down the
Shift key as you click;
the Color Picker tool will
change and become a
white-colored
eyedropper.
5-34 Microtek User's Guide for Windows
The Color Picker tool allows you to sample color
from an area of an image, and to designate a new
shadow or highlight point.
With the Color Picker tool, you can determine the
color values for any pixel in an image. When you
click on the Color Picker tool and pass over a pixel,
the value of that pixel will be displayed in the
Information window, based on the sample size also
selected in the Information window. Pixel-value
information is useful especially when you're making
color adjustments based on color values. (For more
details, see the section The Information Window.)
Click Reset to
restore settings
To restore original settings:
1 Click on the Window Expansion but-
ton in the Settings Window to see the
bottom half of the window.
2 When the expanded window ap-
pears, click on the Reset button.
When a dialog box appears, choose
Shadows and Highlights, then click
on Reset to close the dialog box.
Window
expansion
button
Select a color
channel
