Using the standard film holder

Use the standard film holder to scan film of the following sizes: 4"
x 5"; 60 mm x 60 mm; 60 mm x 70 mm; and 35 mm x 35 mm films.
A. Scanning without the film mount
Follow this procedure to scan 4" x 5" film. For all others size, see
the procedure Scanning with the film mounts.
Place the standard film holder on an even surface, then open
1
the film holder.
2 Place the film upright and facing up inside the standard film
holder, and rest the upper and left edges against the three guide
pins for positioning.
Be careful that the guide pins do not puncture the film when
you place the film inside the film holder.
Film is held
in place by
guide pins.
Operating the scanner...
Guide pins
Hardware Installation 2-47
