Microtek ScanMaker s380 Supplement Manual

Features, scenarios, and information
Hide thumbs Also See for ScanMaker s380:
Table of Contents

Advertisement

Quick Links

Supplement
The ScanMaker s480/s380 is a high-performance scanner with the versatility to scan
photos and film. Features include 48-bit color, resolution of 4800 dpi (for s480) or 3800
dpi (for s380), scan bed size of 8.5" x 11.7", and seven Smart-Touch buttons on the
front panel for easy access to scanner functions. The s480/s380 has a built-in
transparency adapter for scanning film up to 5" x 10", and includes four film holders
to accommodate 35mm slides, 35mm filmstrips, 4" x 5" film, and medium format film up
to 6 x 17 cm. Also featured is ColoRescue™ -- Microtek's one-touch color restoration
to revive faded color in both photos and film.
Contents
Getting to Know Your ScanMaker s480/s380 .................................................. 1
Features of the ScanMaker s480/s380 ............................................................. 2
Taking a Closer Look ........................................................................................ 3
How the Smart-Touch Scanner Buttons Work .............................................. 4
Scanning Scenarios ......................................................................................... 5
Scanning Photos (1) ....................................................................................... 6
Scanning Photos (2) ....................................................................................... 7
Copyright © 2007 Microtek International, Inc.
October 2007
ScanMaker s480/s380 features, scenarios, and information

Getting to Know Your ScanMaker s480/s380

http://www.microtek.com
Scanning Film .................................................................................................. 9
Using the FilmView ............................................................................. 9
A. Scanning 35mm Filmstrips .......................................................... 10
B. Scanning 35mm Slides ................................................................. 12
D. Scanning 4" x 5" Film .................................................................... 14
Specifications / System Requirements ........................................................ 15
FCC Compliance Statement .......................................................................... 16

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ScanMaker s380 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microtek ScanMaker s380

Summary of Contents for Microtek ScanMaker s380

  • Page 1: Table Of Contents

    5" x 10", and includes four film holders to accommodate 35mm slides, 35mm filmstrips, 4" x 5" film, and medium format film up to 6 x 17 cm. Also featured is ColoRescue™ -- Microtek's one-touch color restoration to revive faded color in both photos and film.

  • Page 2: Features Of The Scanmaker S480/S380

    ColoRescue's one-click, automatic color recovery process is simple and straightforward, involving no learning curve or hassle. • Microtek ScanWizard 5 scanning software: ScanWizard 5 features full scanning tools that both novice and experienced scanner users will find productive and easy to use.

  • Page 3: Taking A Closer Look

    Taking a Closer Look Scanner lid, with built-in transparency adapter Horizontal ruler (top ruler) Glass surface (Scan bed) Cancel/ Scan Copy E-mail Custom Setup FilmView Hi-Speed USB port (1) 9-pin accessory port (with built-in Power switch transparency adapter Power connector securely connected) ScanMaker s480/s380 Supplement...

  • Page 4: How The Smart-Touch Scanner Buttons Work

    Microtek Scanner Configuration (MSC) utility. You can use the MSC, for instance, to define how many copies are to be printed of your scan every time you hit the “Copy”...

  • Page 5: Scanning Scenarios

    Scanning Scenarios The following pages provide various scenarios for scanning with the ScanMaker s480/s380, including the following: • Scanning photos (1). This scenario can also be your first scan in order to familiarize yourself with scanning basics. It makes use of the Standard Control Panel in ScanWizard 5.

  • Page 6: Scanning Photos (1)

    Scanning Photos (1) This scenario makes use of the Standard Control Panel. 1. Raise the scanner lid, and place the photo to be scanned face down on the scanner glass surface. Position the top end of the photo towards the back of the scanner 2.

  • Page 7: Scanning Photos (2)

    Scanning Photos (2) This scenario makes use of the Advanced Control Panel. 1. Raise the scanner lid, and place the photo to be scanned face down on the scanner glass surface. Position the top end of the photo towards the back of the scanner.
  • Page 8 ScanMaker s480/s380 Supplement...

  • Page 9: Scanning Film

    Note: If the light source of the FilmView is in “Sleep” mode, press the scanner's Custom button to exit or halt sleep mode. For more details on the Custom button, see the online help of the Microtek Scanner Configuration (MSC). ScanMaker s480/s380 Supplement...

  • Page 10: Scanning 35Mm Filmstrips

    A. Scanning 35mm Filmstrips To scan 35mm filmstrips, use the 35mm filmstrip holder, which can simultaneously hold three strips of 6 frames each, or a total of 18 frames. 1. Load the filmstrip face down inside the holder. Slide the filmstrip along the slots of the holder until the filmstrip is fully loaded.
  • Page 11 5. In the Preview window of ScanWizard 5, click the Scan Material button or drop-down menu. Choose Negative Film (Negative for Mac OS X) to scan negatives; or choose Positive Film (Positive for Mac OS X) to scan transparencies and slides. 6.

  • Page 12: Scanning 35Mm Slides

    B. Scanning 35mm Slides To scan 35mm slides, use the 35mm slide holder, which can simultaneously hold up to eight 35mm mounted slides 1. Raise the scanner lid, then place the holder on the scan bed. The holder should be positioned against the top ruler of the scanner, with the calibration window facing toward the back of the scanner.

  • Page 13: Scanning Medium Format Film Up To 6 X 17 Cm

    C. Scanning Medium Format Film To scan medium format film, use the 6 x 22-cm film holder. This film holder can accommodate the following: one piece of 6 x 17-cm panoramic film; four pieces of 6 x 4.5-cm film; two pieces of 6 x 6-cm film; two pieces of 6 x 7-cm film; or two pieces of 6 x 9-cm film.

  • Page 14: Scanning 4" X 5" Film

    D. Scanning 4" x 5" Film To scan 4" x 5" film, use the 4" x 5" film holder, which can hold two pieces of 4" x 5" film at a time. 1. Load the film face down inside the holder. Slide the film along the slots of the holder until the film is fully loaded.

  • Page 15: Specifications / System Requirements

    Reflective: 8.5" x 11.7" (216 mm x 297 mm) Transparent: 5" x 10" (127 mm x 254 mm) Resolution Optical: 4800 dpi x 9600 dpi (ScanMaker s480); 3200 dpi x 6400 dpi (ScanMaker s380) Interpolated: 65,535 dpi (PC); 32,767 dpi (Mac) Interface Hi-Speed USB (USB 2.0) Dimensions (L x W x H) 17.99"...

  • Page 16: Fcc Compliance Statement

    (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Responsible Party: Loi Han Microtek Lab, Inc. 16941 Keegan Avenue Carson, CA 90746 Phone: 310-687-5800 Fax: 310-687-5950...

This manual is also suitable for:

Scanmaker s480
