The Preview Area

The Preview Area option in the Preview Setup dialog box lets
you select the size of your preview area. Choose from the
following options: letter, A4, legal, maximum size, or custom
size.
• Maximum refers to the maximum scan area that can be
supported by your particular scanner model.
• Custom will appear if you enter your own specifications
in any of the edit boxes (Top, Left, Width, Height).
• The Top, Left, Width and Height edit boxes allow you to
specify the dimensions of the preview area. Top and Left
refer to the starting points of the preview area on the x
and y coordinates. Width is the expanse of the preview
area, and Height is the depth of the preview area.
• The unit of measurement, indicated on the right side of
the Top box, reflects the unit selected in the Settings
window.
Size of preview area if
preview setup is 8. 5" x 11"
To set the preview area:
1 Choose the Preview Area size. If you enter any of the edit
boxes marked Top, Left, Width, or Height, the Preview
Area size automatically changes to Custom.
Click OK to accept the settings; click Cancel to abandon.
2
3 To make the new preview dimensions take effect, do a
new preview by clicking on the Preview button. In a few
moments, the new preview area will appear.
5-22 Microtek User's Guide for Windows
Size of preview area if
preview setup is 6" x 9"
