Start Here
Installing your Microtek S500DC Scanner
1.
Unpack Contents
Unpack your scanner package and check
for major components.
1. Scanner
2. Power cord
3. USB cable
2.
Install Software
1. Visit the Microtek website at https://www.microtek.com.
2. Use the search
page associated with this product.
3. Download the necessary drivers and software marked as "Yes" on the download list, based on
your operating system.
4. Once the download is finished, double-click the downloaded file (*.exe) to begin the installation
process.
5. After installing all the required drivers and software, restart your computer.
NOTE: The file download process may take some time. The duration may vary based on your internet speed,
bandwidth, file size, and other factors. Please be patient during the download. If you encounter any issues or
need further assistance, please contact Microtek Customer Service Department.
Copyright © 2024 Microtek International, Inc. https://www.microtek.com
I49-005533 A, 11/2024
function to find the product "S500DC" and navigate to the "Downloads"
2
1
1
3
Advertisement
Related Manuals for Microtek S500DC
Summary of Contents for Microtek S500DC
- Page 1 1. Visit the Microtek website at https://www.microtek.com. 2. Use the search function to find the product “S500DC” and navigate to the “Downloads” page associated with this product. 3. Download the necessary drivers and software marked as “Yes” on the download list, based on your operating system.
- Page 2 4. Press and hold the Power button ( ) on left side of the scanner's front panel for about 3 seconds until the LCD screen activates. Once the LCD screen lights up, it will display the ”MICROTEK” logo, followed by ”Ready”, indicating that the scanner is detected by your system and is ready for use.
- Page 3 Loading a Stack of Documents 1. Fan out the stack of documents to separate the pages, then align the top edges neatly before loading them into the feed tray. 2. Load the stack into the feed tray with the side to be scanned facing up and the top end oriented toward the inside of the scanner.
- Page 4 3. Go to “Scan > Select device source”. Select the scanner driver “Microtek A3FZ Scanner” from the window that appears, and then click OK. Once the scanner is found, the status bar will show the message “Device Microtek A3FZ Scanner is open”, indicating that the scanner is prepared for scanning.
- Page 5 Fixing Paper Jams If paper jams or other abnormal situations occur during scanning, please follow these steps to clear paper jams. Paper Jammed at the Output slot Gently pull the jammed paper out from the output slot in the direction shown in the picture. Paper Jammed Inside the Scanner 1.
- Page 6 If you encounter issues while using the scanner, please first refer to the ”Troubleshooting” section of the scanner's user manual available on the Microtek website for common problems, and follow the recommended steps for a possible solution. If the issue still remains, please contact the Microtek Customer Service Departement for further assistance.
- Page 7 To ensure optimal performance from your scanner, it is important to regularly clean several critical components of the scanner, including sensors, rollers, and glass surfaces. For detailed cleaning instructions, please refer to the scanner's user manual available on the Microtek website. Pickup roller...
- Page 8 1. S500DC scanner user manual 2. Microtek DocWizard EX software manual To access these manuals, visit the Microtek website at www.microtek.com. Search for the product keyword to find the product’s “Downloads” page. Then, download the manual you wish to view.
