ScanMaker i300
Installing and Getting Started
The ScanMaker i300 with integrated Digital ICE
speed color scanner with automatic photo restoration capabilities. It has a Hi-Speed
USB (USB 2.0) interface, 4800 x 2400-dpi optical resolution, and comes with 7 Smart-
Touch buttons plus a Power button for easy access to scanner functions. Important
features include:
• With the Digital ICE
Energy Star Notice
As an ENERGY STAR Partner,
Microtek International, Inc.
has determined that this
scanner meets the ENERGY
STAR guidelines for energy
efficiency.
Trademarks
Microtek
®
, ScanMaker
TM
, and
®
ScanWizard
are trademarks
or registered trademarks of
Microtek International, Inc.
Macintosh
®
and Apple
®
are
registered trademarks of
Apple Computer, Inc.
Windows
®
is a registered
trademark of Microsoft
Corporation. All other
• USB 2.0 is capable of data transfer rates of up to 480MB/sec. and is backward
products or name brands are
trademarks of their
respective holders.
Important
Documents you scan may be
• The Smart-Touch buttons provide you with an intuitive and easy way to access
protected under copyright
law. The unauthorized use of
such documents could be a
violation of the rights of the
copyright holder. Microtek
bears no responsibility for
the unauthorized use of
copyrighted materials.
Copyright©2003 Microtek International, Inc. http://www.microtek.com
I49-003602 C, October 2003
feature built into the
hardware and software
of the ScanMaker i300,
this scanner can
automatically map,
identify and eliminate
unwanted surface
defects on your photos.
The ScanMaker i300
removes creases,
scratches and other
defects, bringing
photos back to near-
original condition.
compatible with the original USB standard, providing the high/low data transfer
rate via the included Hi-Speed USB cable.
frequently used scanner functions. For details on how to use the scanner buttons
and how to configure the parameters for each button, refer to the last page of this
document and additionally to the online help of the Microtek Scanner
Configuration (MSC) program.
TM
for Photo Prints is a 48-bit, high-
Cancel/
Setup
Scan
Copy
E-mail
OCR
Power
Custom
Scan-to-Web

Advertisement

Table of Contents
loading

Related Manuals for Microtek ScanMaker i300

Summary of Contents for Microtek ScanMaker i300

  • Page 1 Microtek document and additionally to the online help of the Microtek Scanner bears no responsibility for the unauthorized use of Configuration (MSC) program.

  • Page 2: System Requirements

    *Please note: Hi-Speed USB (USB 2.0) is a new standard which is backward compatible with USB 1.1. To achieve USB 2.0 throughput speeds, a USB 2.0 supported system is required. ScanMaker i300 Installing and Getting Started Color, grayscale, and black-and-white in a single scanning pass True 48-bit color (approx.

  • Page 3: Step 1. Unpacking The Scanner

    ScanWizard 5 Quick Reference Guide, and other inserts Step 2. Unlocking the Scanner 1. With the scanner power off, turn the scanner on its side to see the locking screw at the bottom of the scanner. 2. Using a coin, turn the locking screw clockwise until the arrow mark points to the “...

  • Page 4: Step 3. Installing The Software

    Do not turn off your computer during software installation. 4. Click EXIT on the Microtek Software Installer screen when all the software has been installed. 5. Install the image-editing software application, which is on a separate CD-ROM included in your scanner package.

  • Page 5: Step 4. Connecting The Scanner To Your Computer

    Speed USB card in your computer, please refer to the documentation that came with your Hi-Speed USB card. 1. Plug the power adapter connector into the back of the scanner, and plug the other end into a wall outlet or other power source.
  • Page 6 For Macintosh users (with a built-in USB port) 3. Press the scanner's power button to turn on the scanner; the light on the scanner's front panel will illuminate and stay lit. Your system will detect the scanner automatically. ScanMaker i300 Installing and Getting Started...

  • Page 7: Step 5. Your First Scan

    5 Standard Control Panel. When ScanWizard 5 launches, it automatically performs a fast preview of the material on your scanner glass surface and displays it in the preview area. 3. In the preview window, you can resize the scan frame (floating dotted line) around the image by dragging on the edge or corner of the scan frame to determine the final size of the actual scan.

  • Page 8: Scanning Damaged Photos

    Restoration Template" on the scanner bed. Position the damaged photo within the cut-out area of the template, with the photo placed face down on the scanner bed. Photo prints up to 6" x 9" in size can be accommodated within the template area.
  • Page 9 Before After Note: Microtek is always working to enhance ScanWizard 5. For the most recent version of ScanWizard 5 with the latest enhancements, visit www.microtekusa.com and download the most current driver. Scan Material icon...

  • Page 10: How The Scanner Buttons Work

    How the Scanner Buttons Work The ScanMaker i300 is equipped with 7 Smart-Touch buttons (+1 Power button) for easy access to frequently used scanner functions. The Smart-Touch buttons are Cancel/Setup, Scan, Copy, E-mail, OCR, Scan-to-Web, and Custom. To carry out a specific task, simply press the corresponding button on the scanner.
