Rexroth IndraDrive CsDrive Systems with HCS01

X3, mains connection

Notes on installation
Important notes
WARNING
Exclusively operate the device
● with plugged on connectors (even if there haven't been any lines con‐
nected to the connectors) and
● with connected equipment grounding conductor!
● The equipment grounding conductor is connected directly to the device
and not via the connection point X3 (see
ment Grounding Conductor" on page
● Measure the necessary cross section of the connection cables accord‐
ing to the determined phase current I
● Single-phase mains connection (outer conductor and neutral conductor):
Connection to X3 can be made via L1, L2 or L3.
NOTICE
Provide strain relief for the terminal connectors of the device in the control
cabinet.
Bosch Rexroth AG
Mounting and installation
Lethal electric shock by live parts with more
than 50 V!
chapter "Connection of Equip‐
127).
and the mains fuse.
LN
Risk of damage to the device!
129/341
