258/341
Bosch Rexroth AG
Cables, accessories, additional components
8.2.2
DC Bus Connector (RLS0778/K06)
Use
Connector for connecting
●
the DC buses of several HCS01.1E-W00xx-x-03 drive controllers
●
an HCS01.1E-W00xx-x-03 drive controller to a DC bus capacitor unit
Fig. 8-11:
Connecting the DC Buses via DC Bus Connectors
DC bus connector
Order code:
RLS0778/K06
Tab. 8-5:
DC Bus Connector
DOK-INDRV*-HCS01******-PR05-EN-P
Rexroth IndraDrive CsDrive Systems with HCS01
DC bus connector at device
(connection point X77)
