Tions - Bosch Rexroth IndraDrive CsDrive System with HCS01 Project Planning Manual

DOK-INDRV*-HCS01******-PR05-EN-P
Rexroth IndraDrive CsDrive Systems with HCS01
Spring terminal (connector)
Connection cable
Stranded wire
Stripped length
Current carrying capacity of outputs X6
Time constant of load
Number of switching operations at maxi‐
mum time constant of load
Switching frequency
Short circuit protection
Overload protection
Motor holding brake: selection
Motor holding brake: installation
instructions
Unit
mm
2
AWG
mm
A
ms
Hz
X6.3 against X6.4 (output for controlling the motor holding brake)
X6.3 against X6.4 (output for controlling the motor holding brake)
Tab. 6-9: Function, pin assignment
Maximum current carrying capacity of outputs X6: 1.25 A
⇒ R = U / 1.25 A
br (min) br (max)
R : Minimum allowed resistance of the motor holding brake
br (min)
U : Maximum supply voltage of the motor holding brake
br (max)
If U = 24 V +5% = 25.2 V, this results in:
br (max)
R = 20.16 Ω (applicable to all operating and ambient conditions)
br (min)
Make sure the power supply for the motor holding brake at the motor is suffi‐
cient. You have to take into account that voltage drops on the supply line.
Use connection lines with the highest possible cross section of the single
strands.
Use an external contact element in accordance with the required safety cate‐
gory, if you wish to supply motor holding brakes with higher currents than the
allowed current load at X6. Make sure to comply with the required minimum
current consumption of 100 mA when using the external contact element.
Otherwise, the brake current monitoring unit signals an error.
Bosch Rexroth AG
Mounting and installation
Min.
0,25
24
10
-
-
Wear-free electronic contact
-
139/341
Max.
1,5
16
1,25
50
0,5
