Bosch Rexroth IndraDrive CsDrive System with HCS01 Project Planning Manual page 99

DOK-INDRV*-HCS01******-PR05-EN-P
Rexroth IndraDrive CsDrive Systems with HCS01
HCS01.1E-W0003, -W0006, -W0009, -W0013
Clock frequency Maximum leakage capacitance
[kHz] (Motor + cable) per device [nF]
4
8
12
16
Tab. 4-32: Clock frequency, leakage capacitance, motor cable length
HCS01.1E-W0005, -W0008
Clock frequency Maximum leakage capacitance
[kHz] (Motor + cable) per device [nF]
4
8
12
16
Tab. 4-33: Clock frequency, leakage capacitance, motor cable length
HCS01.1E-W0018, -W0028
Clock frequency Maximum leakage capacitance
[kHz] (Motor + cable) per device [nF]
4
8
12
16
Tab. 4-34: Clock frequency, leakage capacitance, motor cable length
HCS01.1E-W0054
Clock frequency Maximum leakage capacitance
[kHz] (Motor + cable) per device [nF]
4
8
12
Tab. 4-35: Clock frequency, leakage capacitance, motor cable length
Select the appropriate mains connection (supply unit/converter, mains choke,
mains filter) from the tables in the corresponding chapter (see
bining transformer, mains filter and mains choke" on page
Bosch Rexroth AG
Combining the individual components
Motor cable length
33
17
13
5
Motor cable length
34
18
14
6
Motor cable length
40
24
20
12
Motor cable length
85
43
30
103).
97/341
[m]
40
20
15
5
[m]
40
20
15
5
[m]
40
20
15
5
[m]
75
38
25
chapter "Com‐
