System Components; Hcs01 Drive Controllers; Type Code - Bosch Rexroth IndraDrive CsDrive System with HCS01 Project Planning Manual

DOK-INDRV*-HCS01******-PR05-EN-P
Rexroth IndraDrive CsDrive Systems with HCS01
1.2.2

System components

HCS01 drive controllers

Short type designation 1 2 3 4 5 6 7 8 9
Example: H C S 0 1 . 1 E - W 0 0 1 3 - A - 0 2 - E - S 3 - E C - N N - N N - N N - F W
①
① Product:
HCS = HCS
② Series:
01 = 01
③ Design:
1 = 1
④ Power supply unit:
E = Feeding
⑤ Cooling type:
W = Air, internal
⑥
Maximum current
0003 = 3 A
0005 = 5 A
0006 = 6 A
0008 = 8 A
0009 = 9 A
0013 = 13 A
0018 = 18 A
0028 = 28 A
0054 = 54 A
⑦ Degree of protection:
A = IP20
⑧
Mains connection voltage
02 = 3 × AC 110 ... 230 V
03 = 3 × AC 200 ... 500 V
⑨
Control section design
A = ADVANCED
B = BASIC
E = ECONOMY
⑩
Communication
S3 = sercos 3 / EtherCAT
CC = sercos 3 master (cross communication)
ET = Multi-Ethernet

Type code

1
0 1 2 3 4 5 6 7 8 9
② ③ ④ ⑤ ⑥
1) :
1) :
2) :
2) :
2
0 1 2 3 4 5 6 7 8 9
⑦ ⑧ ⑨ ⑩ ⑪
