Table 3-11.Configuring the DSLPipe 50S as CPE
Scenario
6. Assume you are using NAT.
10.10.10.10 is the gateway address.
You are setting up ATM over SDSL
with Vpi set to and Vci set to 10. The
Data Rate parameter is set to 528
Kbps and you are using the unit as
CPE. Assume you will be using a VC
connection with IP routing.
Note: The * to the left of a field
indicates that it is a required field.
You must fill in a value for the field.
DSLPipe/CellPipe Quick Setup
DSL-Cell-50S configuration
Configure >
Chan Usage =
Leased/Unused
My Name=
* My Addr =
204.215.204.215 (address
belongs to the local sub-
net)
* Rem Name = ex6
* Rem Addr = 10.10.10.10
* Encaps = ATM
* Mux Type = ATM-VC
* Vpi = 1
* Vci = 10
* Route = IP
Bridge = No
Send Auth = N/A
Send PW = N/A
Recv Auth = N/A
Recv PW = N/A
Rate Mode = singlebaud
* SDSL Line Rate = 528000
* Unit Type = CPE
(continued on the next page)
