Connecting DSL-Cell-50A or DSL-Cell-20A cables (continued)
Description
3 Connect the power cable to the
CellPipe and plug the other end
into a wall outlet. Connect to the
wall outlet last.
There is no power switch.
Connecting the power cable
turns on the CellPipe.
4 To configure the CellPipe,
connect a serial cable from the
CellPipe to your computer. You
can use the adapter that is
provided.
You must provide your own
serial cable.
After connecting the cables, go to page 1-22 to check light activity.
DSLPipe/CellPipe Quick Setup
Illustration
N
W A
B T
1 0
L
IN A
R M
T E
R
P W
N
W A
B T
1 0
L
IN A
R M
T E
R
P W
Installing the unit
DSLPipe/CellPipe Quick Setup
1-11
