Installation Guide
Cajun P118SX/LX
S
E
S
TACKABLE
THERNET
WITCH
Cat No. 130010 Rev.0 December 1998

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cajun P118LX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lucent Technologies Cajun P118LX

  • Page 1 Lucent Technologies Installation Guide Cajun P118SX/LX TACKABLE THERNET WITCH Cat No. 130010 Rev.0 December 1998...
  • Page 3: Safety Precautions

    Preface Important information SAFETY PRECAUTIONS CAUTION – TO REDUCE THE RISK OF ELECTRIC SHOCK AND FIRE All servicing should be undertaken ONLY by qualified personnel. The parts inside the unit CANNOT be serviced or repaired by the end user. Please call your service representative for assistance.
  • Page 4 Austauschen einer durchgebrannten Sicherung NUR mit der gleichen Sorte und Belastbarkeit wie sie auf der Sicherheitsaufschrift markiert ist. Die Aufschrift befindet sich neben der Stromzufuhr wo sich auch der Sicherungskasten befindet. Bedienen Sie das Gerät NICHT an einer Stelle an der die Umgebungstemperatur 50ºC übersteigt.
  • Page 5 Regulatory Approvals and Safety Information for the Cajun P118SX/LX Products LASER SAFETY The Cajun P118SX multi-mode transceiver and the Cajun P118LX single mode transceiver are a Class 1 laser product. They comply with IEC 825-1 and Food and Drug Administration (FDA) 21 CFR 1040.10 and 1040.11.
  • Page 7 Chapter 1 Overview This guide is divided into the following main sections: œ Overview: A general description of the features of the Cajun™ P118. œ Installation: Instructions for getting the Cajun P118 and Cajun P110 stack up and running. Cajun P118 Installation Guide...
  • Page 8 A stack requires a Cajun P110 NMA to link the switches. The units are physically linked using the Exoplane™. Note: You need to install a Cajun P110 NMA in the P118SX and P118LX switches in order to operate them in stand-alone mode.
  • Page 9: Chapter 2 Preliminary Settings

    Two auto-negotiation 1000Base-X ports. P118SX 1000Base-SX ports œ 220m over 62.5 µm MMF or œ 550m over 50 µm MMF. P118LX 1000Base-LX ports œ 5 km over SMF or œ 550m over MMF with special patch cord. Cajun P118 Installation Guide...
  • Page 11: Installation

    Chapter 2 Installation Default Values Note: The management-set default values are those defined in Cajun P110 NMA agent version 8.6. If you download or install a later version of the agent software, please refer to the Cajun P110 NMA Release Notes for any changes. Before you install the Cajun P118, check Table 1 which shows the default values for key parameters and how you can change them.
  • Page 12: Setting The Dip Switches

    ON: certain Cajun P110 switch settings are determined by the DIP switches, and can only be monitored, but not changed, by the console. OFF: the DIP switch settings are ignored and the Cajun P110 functionality is controlled from the console via the Cajun P110 NMA.
  • Page 13 TAG 1, TAG 2 –802.1Q VLAN Tagging mode (TAG 1 is for port 1 and TAG 2 is for port 2). VLAN Tagging transfers across the backbone packets with VLAN and priority. By carrying this information across the inter-switch link, VLAN Tagging makes it possible to distribute VLANs across the organization. This tagging facility allows you to make two 802.1Q-compliant hubs act as a single logical device.
  • Page 14 The procedure for getting the Cajun P118 up and running depends on whether the switch is to operate standalone or as part of a stack. First, attach the adhesive rubber legs to the base of the Cajun P110 switch. If the switch is to be rack mounted, do not attach the legs.
  • Page 15 Lucent representative. Figure 2 Rear view of a Cajun P110 switch stack, showing how the switches are linked via the Exoplane cables. A Cajun P110 NMA resides in the uppermost switch. Two terminators are supplied with the Cajun P110 NMA. Insert the two terminators into the lowest two connectors at the bottom of the stack, as shown in Figure 2.
  • Page 16 Chapter 2 Installation Notes: œ If Cajun P110 NMA in the stack contains the software version 8.6 or higher (as specified in the Cajun P118 Release Notes) or higher, the stack is now fully operational œ When a new version of agent software becomes available, you should perform software download to benefit from the extra capabilities provided.
  • Page 17 Stacking them in this way will allow the switches to be easily connected using the Exoplane cables. Secure the switch in the rack using the screws. Use one screw on each side. Do not overtighten the screws to avoid damaging the plastic.
  • Page 18 Chapter 2 Installation Diagnostics Table 3 and Table 4 explain the meaning of the Cajun P118 diagnostic LED indicators. Figure 4 The Cajun P118 Front Panel LEDs and Buttons Table 3 Meaning of the Cajun P118 Front Panel Buttons Button Function Meaning Select...
  • Page 19 Status Meaning Mains power not connected Mains power connected Blink Working on back-up power supply No agent in switch Switch contains an active agent Blink once Link Test Fail. Blink twice Partition No Collision Collision occurred on line No activity...
  • Page 20 Lucent Technologies Inc., NJ 07920. Cajun and CajunView are trademarks, and in some jurisdictions may be registered trademarks of Lucent Technologies or its affiliated companies. Other trademarks appearing in this document are the property of their respective owners. © Copyright 1998 Lucent Technologies. All rights reserved.
