Table 3-11.Configuring the DSLPipe 50S as CPE
Scenario
3. Assume you are setting up ATM
over SDSL with VPI = 5, VCI = 20.
The data rate is set to 144 Kbps and
you are using the unit as CPE.
Assume you will be using a LLC
connection with bridging. Also
assume that you want to specify a
constant rate of 1000 cells/second.
Note: The * to the left of a field
indicates that it is a required field.
You must fill in a value for the field.
DSLPipe/CellPipe Quick Setup
DSL-Cell-50S configuration
Configure >
Chan Usage =
Leased/Unused
My Name =
My Addr =
* Rem Name = ex3
Rem Addr =
* Encaps = ATM
* Mux Type = ATM-LLC
* Vpi = 5
* Vci = 20
Route = None
Bridge = Yes
Send Auth = N/A
Send PW = N/A
Recv Auth = N/A
Recv PW = N/A
Rate Mode = singlebaud
* SDSL Line Rate - 144000
* Unit Type = CPE
(continued on the next page)
