Steps to setting up your DSLPipe/CellPipe unit

To set up your DSLPipe/CellPipe, perform the following steps:
Step
1
2
3
4
5
DSLPipe/CellPipe Quick Setup
Description
Check DSLPipe/CellPipe model. The model name
is printed on the bottom of the DSLPipe/CellPipe
box.
Connect the cables as required for your
DSLPipe/CellPipe model.
• If you are connecting to an Ethernet hub and
you are not using the DSL-HS or the
DSL-HST model, you must supply your own
straight-through cable.
• To configure the DSLPipe/CellPipe, you must
supply your own serial cable.
Check the activity of DSLPipe/CellPipe LED
lights.
If you are configuring:
• a DSLPipe unit, read the description of the
default configuration.
• the CellPipe 50A or the CellPipe 50S, read the
information on configuring these pipes.
• the CellPipe 20A, read the desciption of the
default configuration.
To change the default configuration, see the
sample scenarios.
Before you can change the configuration, you must
establish a serial connection between your
workstation and the DSLPipe/CellPipe unit. You
must also have software for vt100 emulation.
Installing the unit
DSLPipe/CellPipe Quick Setup
Go to page
page 1-8
page 1-10, page 1-12,
page 1-14, page 1-16,
page 1-18
page 1-20
page 1-22
page 3-2/ page 3-13
page 3-6
page 3-8
page 3-18 (Also see
page 3-8 and
page 3-13)
1-7
