Installing the unit
DSLPipe/CellPipe Quick Setup

Connecting DSL-HSTB cables

Description
1 Connect the yellow crossover
Ethernet cable from the port
labeled LAN on the DSLPipe to
the Ethernet adapter in your
computer.
Note: To connect the DSLPipe
to an Ethernet hub, use your own
straight-through Ethernet cable.
2 Connect the blue WAN cable to
the port labeled WAN on the
DSLPipe and plug the other end
into the wall jack.
1-20
Illustration
B T
1 0
R
P W
N
W A
E
O L
N S
C O
B T
1 0
R
P W
N
W A
E
O L
N S
C O
DSLPipe/CellPipe Quick Setup
