Connecting the DSL-Cell-50S or the DSL-S cables (continued)
Description
3 Connect the power cable to the
DSLPipe/CellPipe and plug the
other end into a wall outlet.
Connect to the wall outlet last.
There is no power switch.
Connecting the power cable
turns on the DSLPipe/CellPipe.
4 To configure the
DSLPipe/CellPipe, connect a
serial cable from the
DSLPipe/CellPipe to your
computer. You can use the
adapter that is provided.
You must provide your own
serial cable.
After connecting the cables, go to page 1-22 to check light activity.
DSLPipe/CellPipe Quick Setup
Illustration
W A
B T
1 0
L
IN A
R M
T E
R
P W
B T
1 0
L
IN A
R M
T E
R
P W
Installing the unit
DSLPipe/CellPipe Quick Setup
N
N
W A
1-17
