CellPipe
22A-GX Series
User Guide
September 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CellPipe 22A-GX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lucent Technologies CellPipe 22A-GX Series

Summary of Contents for Lucent Technologies CellPipe 22A-GX Series

  • Page 1 ® CellPipe 22A-GX Series User Guide September 2004...
  • Page 2 Access Safety and Compliance Guide, which can be found at http://www.lucentdocs.com/ins. See the warranty card included in your product package for the limited warranty that Lucent Technologies provides for its products. See Appendix C for further information on regulatory compliance.

  • Page 3: Customer Service

    Customer Service Lucent Technologies is the value added reseller (VAR) of certain CellPipe products. To ensure you receive the latest and most up-to-date information in a timely manner, Lucent is providing you with the latest original equipment manufacturer (OEM) documentation. Thus, references to both Lucent and the OEM might appear in the documentation.
  • Page 4 Obtaining assistance through email or the Internet If your services agreement allows, you can communicate directly with a technical engineer through Email Technical Support or a Live Chat. Select one of these sites when you log in to http://www.lucent.com/support. Calling the technical assistance center (TAC) If you cannot find an answer through the tools and information of Lucent OnLine Customer Support or if you have a very urgent need, contact TAC.
  • Page 5 Preventing static discharge damage Semiconductor devices can be easily and permanently damaged due to electrostatic discharge during installation or removal. A person walking across a floor can generate electrostatic voltages in excess of 5000V. Although you might not notice a discharge of less than 3500V, discharges below 100V can damage semiconductor components.
  • Page 6 Use the following two simple tests to verify that the wrist strap is functioning properly: • Measure the resistance between the wrist strap and its grounding plug. Overall resistance between these two points must be approximately 1 megohm. If it is not, replace the strap. •...

  • Page 7: Table Of Contents

    Table of Contents GETTING STARTED............. 1 ................1 VERVIEW ................2 EATURES ................3 ACKAGING ................. 4 PPEARANCE ............. 6 ARDWARE NSTALLATION ............... 7 ANAGEMENT ..............8 EFAULT ALUES ............. 9 OFTWARE PGRADE ..............10 ONSOLE ETUP WEB INTERFACE MANAGEMENT......11 ................
  • Page 8 Ethernet over ATM (EoA) ..........23 IP over ATM (IPoA) ............25 ................27 RIDGING Bridging ................27 ................28 OUTING IP Route................28 ................30 ERVICES NAT ................. 30 RIP .................. 34 Firewall ................35 IP Filter................36 Domain Name Service (DNS) ......... 40 Blocked Protocols ............
  • Page 9 ..........62 OUTE ONFIGURATION DHCP C ............65 ONFIGURATION NAT C ............68 ONFIGURATION APPENDIX A – SPECIFICATIONS........70 ..........70 ARDWARE PECIFICATIONS ..........71 OFTWARE PECIFICATIONS APPENDIX B – REGULATIONS ........73 FCC P 15 N ............73 OTICE IC CS-03 N ..............

  • Page 10: Getting Started

    CellPipe 22A-GX 1 Getting Started Overview The CellPipe 22A-GX is multi-mode ADSL Router, compliant with ANSI T1.413 Issue 2, ITU G.992.1 (G.dmt) Annex A, G.992.2 (G.lite). CellPipe 22A-GX provides high-speed Internet access via one WAN port over ATM over ADSL, and also connects to a corporate network via one 10/100BaseTX Ethernet port and one USB port.

  • Page 11: Features

    CellPipe 22A-GX Features High speed asymmetrical data transmission on a single twisted copper pair Full rate operations up to 8Mbps downstream (12Mbps to be provided) and up to 1Mbps upstream. G.lite operation up to 1.5Mbps downstream and 512Kbps upstream One 10/100BaseTx Ethernet port and one USB port for PC connection DHCP server...

  • Page 12: Packaging

    CellPipe 22A-GX Packaging This package contains the following items: CellPipe 22A-GX ADSL device unit RJ-45 Cable RJ-11 Cable AC Adapter User’s Manual CD - 3 -...

  • Page 13: Appearance

    CellPipe 22A-GX Appearance Front Panel Label Color Description Status Green Ethernet port is connected. Green USB port is connected. Green Power supply is connected. Blinking Green Training with DSLAM. Green ADSL link is ready. Blinking Booting up. Error. - 4 -...

  • Page 14: Rear Panel

    CellPipe 22A-GX Rear Panel 3 4 5 Label Description Power jack; connect to a power adapter ETHERNET RJ-45 port; connect to a PC or LAN USB port; connect to a PC RESET Reset the modem back to factory settings by holding down on this button RJ-11 or RJ-45 port;...

  • Page 15: Hardware Installation

    CellPipe 22A-GX Hardware Installation The following section describes how to set up CellPipe 22A-GX with a single computer. As shown in the diagram below, both the USB and Ethernet ports can be used at the same time. However it is recommended that you use only one port during setup.

  • Page 16: Management

    CellPipe 22A-GX Management CellPipe 22A-GX supports simple, flexible, and easy-to-operate methods for management purposes. CellPipe 22A-GX can be managed via the following paths: Local Ethernet Port (Telnet) – connect the Ethernet port to your local area network or to directly to a PC. “Telnet” CellPipe 22A-GX from any workstation in the LAN.

  • Page 17: Default Values

    CellPipe 22A-GX Default Values CellPipe 22A-GX is pre-configured with the following parameters; you may also re-load the default parameters by rebooting the router into the Default configuration from the web browser. Default Mode: Bridge User Name: root Password: root Bridge Mode Setting WAN and ADSL Ethernet (local) IP: 192.168.1.1 Local Line Code: Auto...

  • Page 18: Software Upgrade

    CellPipe 22A-GX Software Upgrade You may easily upgrade CellPipe 22A-GX embedded software by obtaining the compressed upgrade kit from the service provider then following the steps: Extract the ZIP file for updated firmware. Connect CellPipe 22A-GX via the local ethernet port or remote ADSL link.

  • Page 19: Console Setup

    CellPipe 22A-GX Console Setup Connect the RS-232 console port to an ASCII data terminal or a PC with Widows serial Terminal mode of VT-100 (Hyper Terminal). To start the Hyper-terminal, follow the steps below. Start "Hyper-terminal" program On Windows 98 or Windows NT Click on the Start button Programs Accessories...

  • Page 20: Web Interface Management

    CellPipe 22A-GX 2 Web Interface Management Overview The Web management is provided in order to manage the ADSL device as easily as possible. It provides a very user-friendly configuration and graphical interface through a Web based platform. You can configure a bridge or a router, as you feel appropriate. In the section below, each configuration item is described in detail.

  • Page 21: Login

    CellPipe 22A-GX Login The window Enter Network Password will pop up while starting the configuration. With the window open, type admin for both User Name and the Password. You can also edit the Username and Password or add new users. After you log into the web interface, you will notice that it is divided into seven different sections, or tabs.

  • Page 22: Home

    CellPipe 22A-GX HOME After logging in, the first tab that will be displayed is the Home tab. Under this tab, the System View page is displayed. This page displays a summary of the interfaces and their settings. This page is divided into five sections. The table below describes each section.
  • Page 23 CellPipe 22A-GX Section Name Description Device Displays model name, hardware/software version, device mode, uptime, current time, time zone, daylight savings time, and domain name. Displays operation status, last state, DSL version, and DSL standard. Displays the WAN interface name, WAN Interface encapsulation type, IP address, subnet mask, lower interface, VPI/VCI values, and operational status.

  • Page 24: Lan

    CellPipe 22A-GX Click on the LAN tab to view its sub-menu and configure the LAN settings. The four sub-menu are: LAN Config, DHCP Mode, DHCP Server, and DHCP Relay. Each sub-menu is described below. LAN Config Click on the LAN Config link to change the LAN IP address/ subnet mask, decide where the LAN is getting its IP address from, and enable or disable IGMP.
  • Page 25 CellPipe 22A-GX - 16 -...

  • Page 26: Dhcp Mode

    CellPipe 22A-GX DHCP Mode Click on the DHCP Mode link to select a DHCP setting. From the drop down list, select DHCP Server, DHCP Relay, or None. Click on the Submit button when completed. DHCP Server Click on the DHCP Server link to view the DHCP Server settings. The table displays the DHCP server settings, including start IP, end IP, domain name, gateway address, and status.

  • Page 27: Dhcp Relay

    CellPipe 22A-GX DHCP Relay Click on the DHCP Relay link to view the DHCP Relay settings. Fill in the DHCP server IP address in the text boxes and select an interface name from the dorp down list. Click on the Add button to complete the DHCP Relay configuration.

  • Page 28: Wan

    CellPipe 22A-GX Click on the WAN tab to view its sub-menu and configure the WAN settings. The five sub-menu are: DSL, ATM VC, PPP, EOA, and IPOA. Each sub-menu is described below. Click on the DSL link to view the DSL status. Click on the DSL Param button to view the DSL parameters and the Stats button to view the DSL statistics.
  • Page 29 CellPipe 22A-GX DSL Parameters Click on the Param button to view parameters. Another window will then display parameters, which may be different from shown below, due to the type and speed of the network. Click on the Close button to close the window, or click on the Refresh button to refresh the status.

  • Page 30: Atm Vc

    CellPipe 22A-GX ATM VC Click on the ATM VC link to view the ATM VC table. This table displays the interface name, VPI/VCI values, Mux type, and maximum protocols per AAL5. Click on the trash can icon to delete the current interface, or edit the current interface by clicking on the pencil icon.

  • Page 31: Point To Point Protocol (Ppp)

    CellPipe 22A-GX Point to Point Protocol (PPP) Click on the PPP link to view the PPP configuration table. This table displays PPP information such as: interface name, interface type, protocol, WAN IP, gateway IP, default route, DHCP, DNS, and operation status. Click on the trash can icon to delete the current interface, or edit the current interface by clicking on the pencil icon.

  • Page 32: Ethernet Over Atm (Eoa)

    CellPipe 22A-GX The following is a list of field names and their descriptions. After filling in the table, click on the Submit button when completed. Field Name Description PPP Interface Select an interface name from the drop down list. ATM VC Select an ATM VC from the drop down list.
  • Page 33 CellPipe 22A-GX The following is a list of field names and their descriptions. After filling in the table, click on the Submit button when completed. Field Name Description EoA Interface Select an interface name from the drop down list. Interface Sec Type Select between public, private, or DMZ.

  • Page 34: Ip Over Atm (Ipoa)

    CellPipe 22A-GX IP over ATM (IPoA) Click on the IPoA link to view the IP over ATM configuration table. This table displays IPoA information such as: interface name, interface security type, lower interface, config IP, network IP, subnet mask gateway IP, and status. Click on the trash can icon to delete the current interface, or edit the current interface by clicking on the pencil icon.
  • Page 35 CellPipe 22A-GX Field Name Description IPoA Interface Select an interface name from the drop down list. Conf IP Address Enter the LAN IP address here. Interface Sec Type Select a lower interface name from the drop down list. Netmask Enter the subnet mask here. RFC 1577 Select between Yes or No to use RFC 1577.

  • Page 36: Bridging

    CellPipe 22A-GX Bridging Click on the Bridging tab to view its sub-menu and configure the bridge settings. The six sub-menu are: Bridging, LAN Config, DSL, ATM VC, and RFC 1483 Interface (EoA). The bridging sub-menu is described below. (Each of the other sub-menus is described in the earlier sections.) Bridging Click on the Bridging link to view the Bridge configuration.

  • Page 37: Routing

    CellPipe 22A-GX Routing Click on the Routing tab to view its sub-menu and configure the routing settings. The eight sub-menu are: IP route, IP address, LAN Config, DSL, ATM VC, PPP, EoA, and IPoA. The IP route sub-menu is described below. (Each of the other sub-menus is described in the earlier sections.) IP Route Click on the IP Route link to view the IP route table.
  • Page 38 CellPipe 22A-GX The following is a list of field names and their descriptions. After filling in the table, click on the Submit button when completed. Field Name Description Destination Enter the destination IP address of the router. Netmask Enter the subnet mask of the IP address. Gateway/Next Hop Enter the IP address of the gateway or the next router hop...

  • Page 39: Services

    CellPipe 22A-GX Services Click on the Services tab to view its sub-menu’s and configure the service settings. The six sub-menu are: NAT, RIP, Firewall, IP filter, DNS, and Blocked Protocols. Each one is described in detail below. Click on the NAT link to view the NAT global information table. The table displays the idle times for several protocols;...
  • Page 40 CellPipe 22A-GX NAT Global Info The table displays the idle times for several protocols; you may change the times by clicking Submit button. NAT Entry Rule The table displays NAT route configuration. Click on the trash can icon to delete the current rule or click on the Add button to add another rule.
  • Page 41 CellPipe 22A-GX The following is a list of field names and their descriptions. After filling in the table, click on the Submit button when completed. Field Name Description Rule Flavor Select a rule from the drop down list. Rule ID Enter a rule ID into this text box.
  • Page 42 CellPipe 22A-GX down list, or enter it into the text box. Local Port Select a local port from the drop down list, or enter it into the text box. NAT Translations The table displays the current NAT translations, if any exist.

  • Page 43: Rip

    CellPipe 22A-GX Click on the RIP link to view the Routing Information Protocol (RIP) Configuration table. Routers on your LAN communicate with one another using the Routing Information Protocol. This table lists any interfaces on your device that use RIP (typically the LAN interface), and the version of the protocol used.

  • Page 44: Firewall

    CellPipe 22A-GX Firewall Click on the Firewall link to view the Firewall Configuration table. The Firewall adds security to your network by protecting it from Internet intruders. The following is a list of field names and their descriptions. After filling in the table click on the Submit button Field Name Description Blacklist Status...

  • Page 45: Ip Filter

    CellPipe 22A-GX Max half open TCP Conn. Enter the maximum number of TCP connections. Max ICMP Conn. Enter the maximum number of ICMP connections. Max Single Host Conn. Enter the maximum number of host connections. Log Destination Select a destination for the log file. Email ID of admin Enter the email addresses of up to three administrators.
  • Page 46 CellPipe 22A-GX Click on the Stats button to view the IP filter rule statistics. You may click on the Clear button to clear the table, or click on the Close button to close the window. - 37 -...
  • Page 47 CellPipe 22A-GX To add an IP filter rule, click on the Add button .The table will pop-up in a new window. The following is a list of field names and their descriptions. After filling in the table click on the Submit button Field Name Description Rule ID...
  • Page 48 CellPipe 22A-GX low. Log Tag Enter a name for the log. Start Time Enter a start time for the IP filter. Action Select accept or deny incoming IPs. Interface Select an outgoing interface from the drop down list. Log Option Select to enable or disable logging.

  • Page 49: Domain Name Service (Dns)

    CellPipe 22A-GX Domain Name Service (DNS) Click on the DNS link to view the DNS Configuration table. This page is used for adding and deleting DNS server IP addresses. You may also enable/disable DNS relay from this page. In order to add a DNS server IP addresses follow the steps below.

  • Page 50: Blocked Protocols

    CellPipe 22A-GX Blocked Protocols Click on the Blocked Protocols link to view the list of protocols. This page is used to block or unblock protocols running across the system. Check the box, if you would like the protocol blocked, un-check the box to allow the protocol.

  • Page 51: Admin

    CellPipe 22A-GX Admin Click on the Admin tab to view its sub-menu’s and configure the admin settings. The six sub-menu’s are: User Config, Commit & Reboot, Local Image Upgrade, Remote Image Upgrade Alarm, Diagnostics, and Port Settings. Each one is described in detail below.

  • Page 52: Commit & Reboot

    CellPipe 22A-GX Commit & Reboot Click on the Commit & Reboot link to view the reboot options. This page is used to save the changes into the device’s memory and reboot the device using different options. Click on the Commit button to save the changes. In order to reboot the device, select an option from the drop down list.

  • Page 53: Local Image Upgrade

    CellPipe 22A-GX Local Image Upgrade Click on the Local Image Upgrade link to upgrade the software on the modem from Local site. You may easily upgrade CellPipe 22A-GX embedded software by obtaining the compressed upgrade kit from the service provider and then following the steps: a.

  • Page 54: Remote Image Upgrade

    CellPipe 22A-GX Remote Image Upgrade Click on the Remote Image Upgrade link to upgrade the software on the modem. Enter the IP address where the software is located, the name of the software, and the User name and password of the site. - 45 -...

  • Page 55: Alarm

    CellPipe 22A-GX Alarm Click on the Alarm link to view the list of alarms. The alarms shown in the table have been recorded in response to system events. Click on the Clear button to clear the alarms. - 46 -...

  • Page 56: Diagnostics

    CellPipe 22A-GX Diagnostics Click on the Diagnostics link to test the device. Results will be displayed as pass, fail, or N.A, depending on your settings. Click on the Submit button to begin the diagnostic tests. - 47 -...

  • Page 57: Port Settings

    CellPipe 22A-GX Port Settings Click on the Port Settings link to change the port settings on the device. Change the settings by entering the new value into the text box and click on the Submit button when completed. - 48 -...

  • Page 58: Quick Protocol Setup

    CellPipe 22A-GX 3 Quick Protocol Setup Overview This chapter provides quick steps on setting up the protocols on this device. From this point on, configuration steps are listed for each of the protocols in their respective sections. The seven sections are: •...

  • Page 59: Rfc 1483 Bridge

    CellPipe 22A-GX RFC 1483 Bridge Configuration Table: Protocol RFC1483 Bridge Mode WAN IP The ISP assigns the IP address, or have an IP address assigned from an external/internal DHCP server Modem IP 192.168.1.1 Gateway IP None VPI/VCI 8/81 1. Click on the WAN tab to view its sub-menu and configure the WAN settings, then click on the ATM VC link below it.
  • Page 60 CellPipe 22A-GX 3. Another window will then appear. Enter the VPI/VCI values (8/81) into the VPI and VCI text boxes. Then click on the Submit button to confirm the changes. 4. Click on the EOA link below the WAN tab. 5.
  • Page 61 CellPipe 22A-GX 6. Click on the Bridging tab to view its sub-menu and configure the bridging settings, then click on the Bridging link below it. 7. Select eoa-1 from the drop down list, and click on the Add button. Then click on the Submit button to confirm the changes. 8.

  • Page 62: Pppoe Route Configuration

    CellPipe 22A-GX PPPoE Route Configuration 1. Click on the WAN tab to view its sub-menu’s and configure the WAN settings, then click on the PPP link below it. 2. You will then see the PPP Configuration table. Click on the Add button to add a new PPPoE setting.
  • Page 63 CellPipe 22A-GX 3. Select an interface name: PPP-1. 4. Select a protocol: PPPoE. 5. Default Route: Disable. 6. Security Protocol: Select PAP or CHAP. 7. Login Name: Enter username here (from ISP). 8. Password: Enter password here (from ISP). 9. Click on the Submit button to confirm the changes. - 54 -...

  • Page 64: Rfc 1483 + Nat

    CellPipe 22A-GX RFC 1483 + NAT Configuration Table: Protocol RFC1483 Mode + NAT LAN IP 192.168.1.xxx or assigned by DHCP server Modem IP 192.168.1.1 WAN IP 210.62.8.3 VPI/VC Value 8/81 1. Click on the WAN tab to view its sub-menu and configure the WAN settings.
  • Page 65 CellPipe 22A-GX 3. Another window will then appear. Enter the VPI/VCI values (8/81) into the VPI and VCI text boxes. Then click on the Submit button to confirm the changes. 4. Click on the EoA link below the WAN tab. 5.
  • Page 66 CellPipe 22A-GX 7. Click on the Services tab to view its sub-menu and configure the NAT settings. Click on the NAT link below it. 8. Select NAT Entry Rule from the NAT configuration drop down list, and then click on the Add button to add a NAT entry. 9.

  • Page 67: Pppoa Route Configuration

    CellPipe 22A-GX PPPoA Route Configuration Configuration Table: Protocol PPPoA Route Mode LAN IP 192.168.1.xxx Modem IP 192.168.1.1 Gateway IP Not required VPI/VCI 8/81 Username From ISP Password From ISP 1. Click on the Routing tab to view its sub-menu and configure the Routing settings.
  • Page 68 CellPipe 22A-GX 3. Another window will then appear. Enter the VPI/VCI values (8/81) into the VPI and VCI text boxes. Then click on the Submit button to confirm the changes. - 59 -...
  • Page 69 CellPipe 22A-GX 4. Click on the PPP link in the Routing tab, and then click on the Add button to add a PPPoA configuration. 5. Select an interface name: PPP-1. 6. Select a protocol: PPPoA. 7. Default Route: Enable. 8. Security Protocol: Select PAP or CHAP. 9.
  • Page 70 CellPipe 22A-GX 12. Click on the Admin tab to view its sub-menu and configure the bridging settings. Click on the Commit & Reboot link below it. 13. Select the Reboot from last configuration option from the drop down list, and the click on the Commit and Reboot button. - 61 -...

  • Page 71: Ip O A R Oute C Onfiguration

    CellPipe 22A-GX IPoA Route Configuration Configuration Table: Protocol IPoA Route Mode LAN IP 192.168.1.xxx Modem IP 192.168.1.1 Gateway IP 210.62.8.1 VPI/VCI 8/81 WAN IP 210.62.8.2 1. Click on the Routing tab to view its sub-menu and configure the Routing settings. Click on the ATM VC link below it. 2.
  • Page 72 CellPipe 22A-GX 3. Another window will then appear. Enter the VPI/VCI values (8/81) into the VPI and VCI text boxes. Then click on the Submit button to confirm the changes. 4. Click on the IPoA link in the Routing tab, and then click on the Add button to add an IPoA configuration.
  • Page 73 CellPipe 22A-GX 5. Select an interface name: IPoA-0. 6. Conf. IP Address: From ISP. 7. Net mask: From ISP. 8. Gateway IP Address: From ISP. 9. Login Name: Enter username here (from ISP). 10. Lower Interface: Select aal5-0. 11. Click on the Submit button to confirm the changes. 12.

  • Page 74: Dhcp C Onfiguration

    CellPipe 22A-GX DHCP Configuration 1. Click on the LAN tab to view its sub-menu and configure the LAN settings. Click on the DHCP Mode link below it. 2. From the drop down list, select DHCP Server, and click on the Submit button.
  • Page 75 CellPipe 22A-GX 3. Click on the DHCP Server link under the LAN tab, and click on the Add button. 4. Start IP Address: Enter the Start IP Address (192.168.1.2). 5. End IP Address: Enter the End IP Address (192.168.1.13). 6. Net mask: based on IP address (255.255.255.0). 7.
  • Page 76 CellPipe 22A-GX 11. Select the Reboot from last configuration option from the drop down list, and the click on the Commit and Reboot button. - 67 -...

  • Page 77: Nat C Onfiguration

    CellPipe 22A-GX NAT Configuration 1. Click on the Services tab to view its sub-menu and configure the NAT settings. Click on the NAT link below it. 2. From the NAT Options drop down list, select NAT Rule Entry. 3. Click on the Add button to add a new NAT Rule Entry. - 68 -...
  • Page 78 CellPipe 22A-GX 4. Rule Flavor: Select a Rule flavor from the drop down list (Basic). 5. Rule ID: Enter a number here. 6. Local Address From: Address from where this device will receive IPs. 7. Local Address to: 255.255.255.255 (broadcast) or other. 8.

  • Page 79: Appendix A – Specifications

    CellPipe 22A-GX Appendix A – Specifications Hardware Specifications Local Interface • One 10/100BaseT Ethernet port, IEEE 802.3, RJ-45 connector • One port USB pin type for series B, supports USB 1.1 WAN ADSL Line Interface • For ADSL over POTS, compliant with ITU G.992.1 (G.dmt) Annex A, ITU G.992.2 (G.lite), and ANSI T1.413 issue 2 •...

  • Page 80: Software Specifications

    CellPipe 22A-GX Software Specifications • ATM Cell over ADSL, AAL5 • Supports UBR/GFR, CBR, VBR-rt and VBR-nrt • VPI Range (0-4095) and VCI range (1-65535) • Supports up to 8 PVCs (Bridge Mode), 5 PVCs (Router Mode) • Support OAM F4/F5, AIS, RDI, and loopback cells •...
  • Page 81 CellPipe 22A-GX Configuration and Network Management • DHCP server for IP management • FTP, TFTP, Telnet for local or remote management • TFTP for firmware upgrade and configuration • Web configuration • SNMP v1 and MIB II (RFC 1213) • Auto Detect – VCI/VPI Setup •...

  • Page 82: Appendix B – Regulations

    CellPipe 22A-GX Appendix B – Regulations FCC Part 15 Notice Warning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 to the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a residential environment.

  • Page 83: Ic Cs-03 N Otice

    CellPipe 22A-GX IC CS-03 Notice The Industry Canada label identifies certified equipment. This certification means that equipment meets certain telecommunications network protective, operational, and safety requirements as prescribed in appropriate Terminal Equipment Technical Requirements document(s). The Department does not guarantee that the equipment will operate to the user’s satisfaction.

  • Page 84: Ul Notice

    CellPipe 22A-GX UL Notice The following markings and instructions are provided as bellow. "Disconnect TNV circuit connector before removing cover" or equivalent. "Disconnect TNV circuit connector(s) before disconnecting power." (Instruction) Including the following: -Do not use this product near water for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
