DSL-Cell-50S as CPE
Table 3-11.Configuring the DSLPipe 50S as CPE
Scenario
1. Assume you are setting up only
one Connection profile with the Data
Rate parameter set to 144 Kbps. The
unit is functioning as CPE. You are
setting up ATM over SDSL with Vpi
set to 1 and Vci set to 15. Assume
you will be using a VC connection
with bridging.
Note: The * to the left of a field
indicates that it is a required field.
You must fill in a value for the field.
DSLPipe/CellPipe Quick Setup
DSL-Cell-50S configuration
Configure >
Chan Usage =
Leased/Unused
My Name=
My Addr =
* Rem Name = ex1
Rem Addr=
* Encaps = ATM
* Mux Type = ATM-VC
* Vpi = 1
* Vci = 15
Route = None
* Bridge = Yes
Send Auth= N/A
Send PW = N/A
Recv Auth = N/A
Recv PW = N/A
Rate Mode = singlebaud
* SDSL Line Rate = 144000
* Unit Type = CPE
Configuring the unit
