Configuring the unit
DSLPipe/CellPipe Quick Setup
Table 3-10.Confiuging the CellPipe 50A as CPE
3-28
Example Scenarios
4. Assume you are setting up
on-demand PPP over ATM with VPI
= 5, VCI = 20. Assume you will be
using a LLC connection with IP
routing. Assume you are using PAP
authentication with password lala.
CellPipe Configuration
Configure >
Chan Usage = Switch/Unused
My Addr = 204.215.204.215
Encaps = PPP
Mux Type = ATM-LLC
Vpi = 5
Vci = 20
Configure > Ethernet > Connections>
Station = ex1
Active = Yes
Encaps = PPP
Dial # = N/A
Route IP = Yes
Bridge = No
Dial brdcast = No
Encaps options...
Send Auth = PAP
Send PW = lala
Interface Type = AAL5
Ip options...
LAN Adrs = 10.10.10.10
Telco options...
Call Type = Switched
Group = N/A
Interface options...
MUX Type = ATM-LLC
vpi = 5
vci = 20
Service Type = Unspecified
Service Rate = 0
