Connecting DSL-ACAP or DSL-DMT cables (continued)
Description
3 Connect the power cable to the
DSLPipe and plug the other end
into a wall outlet. Connect to the
wall outlet last.
There is no power switch.
Connecting the power cable
turns on the DSLPipe.
4 (Optional)To change the
DSLPipe default configuration,
connect a serial cable from the
DSLPipe to your computer. You
can use the adapter that is
provided.
You must provide your own
serial cable.
After connecting the cables, go to page 1-22 to check DSLPipe light activity.
DSLPipe/CellPipe Quick Setup
Illustration
N
W A
R
T E
L IT
S P
B T
1 0
L
IN A
R M
T E
R
P W
N
W A
R
T E
L IT
S P
B T
1 0
L
IN A
R M
T E
R
P W
Installing the unit
DSLPipe/CellPipe Quick Setup
1-15
