Specifications

Characteristics Description
Dimensions:
Instrument only
(not including
stacks)
Weight:
Power Supply:
Power
Consumption:
Operating
Temperature:
Humidity:
Microplates
Running without Lids
Width: 85.48 mm (3.365") ± 0.25 mm
(0.009") at the corners
Length: 127.76 mm (5.030") ± 0.25 mm
(0.015") at the corners
Max 14.60 mm (0.575")
Height:
22.0 mm (0.866") using BioStack 4
Lidded Plate Stacks.
Min approximately 10.16 mm (0.400")
BIOSTACK2WR: Length 18.5" (46.9 cm), width 7" (17.8 cm), height
14" (35.6 cm)
BIOSTACK3WR: Length 21" (54 cm), width 8" (21 cm), height 15" (38
cm)
BIOSTACK4: Length 21" (54 cm), width 8" (21 cm), height 16" (40
cm)
BIOSTACK2WR: 24 lbs (10.9 kg)
BIOSTACK3WR: <26 lbs (11.8 kg)
BIOSTACK4: <30 lbs (13.6 kg)
Compatible with 100 to 240 V~ ± 10% @50-60 Hz
40 watts maximum
18°C to 40°C (64.4°F to 104°F)
Operate in a noncondensing humid environment having a maximum
relative humidity of 80% at temperatures up to 31° C decreasing
linearly to 50% relative humidity at 40° C.
Running with Lids
(BioStack 4 Only)
85.48 mm (3.365") ± 0.25 mm (0.009")
at the corners
Width above flange: Min 81.0 mm; Max
83.2 mm
127.76 mm (5.030") ± 0.25 mm
(0.015") at the corners
Typical 96-, 384-, 1536-well plates:
16.9 mm (0.665") plate + lid combined:
plate max is 14.60 mm, except in
on Lid Mode.
7.60 mm (0.299")
BioTek Instruments, Inc.
Specifications | 9
