With this wrist angle
setting:
+90° or 90°
0°
-90°
Right-Side Installation
1. Align the two holes in the mounting bracket with the two holes on the right
side of the BioStack.
2. Using the screwdriver and the two shoulder screws, attach the scanner to the
BioStack.
3. Using lens tissue or a soft cloth moistened with lens cleaner, carefully wipe the
mirror to remove any dust or particles.
4. To complete the installation
Install the barcode scanner on this side of the
BioStack when facing it:
right side
either side
left side
See Install the Scanner Cable Duct on page 97
Install the Barcode Scanner | 95
