Warning: Do not change a switch setting unless explicitly instructed to do so.
Switch 1 All Models
SW1 - 1 Plate Height: Closed = Normal, standard plates; Open = for low-profile
plates.
SW1 - 2 Do Not Change! 2WR = Closed, 3WR = Open.
SW1 - 3 Barcode Scanner: Closed = Not installed; Open = Installed.
SW1 - 4 Closed: Do Not Change!
Switch
BIOSTACK2WR
2
SW2 - 1 Closed = for 10 or 30 plate stacks; Open = for 50 plate stacks
SW2 - 2 Closed: Do Not Change!
SW2 - 3 Wrist Angle: Open = 90°;
Closed = 0°
SW2 - 4 Closed: Do Not Change!

Change Setting for Wrist Angle

Most BioTek instruments require the BioStack wrist to be set at a specific angle.
Follow these instructions to change the wrist angle dip switch setting for your
instrument.
See Wrist Angle Setting Requirements on page 26
1. Turn off the BioStack.
2. Two plugs on the rear wall of the instrument cover two sets of dip switches.
Remove plug #2, the plug on the right when viewing the instrument from the
rear.
3. Using a pencil tip, change the switch settings to suit your instrument:
BIOSTACK3WR/BIOSTACK4
Closed: Do Not Change!
SW2-3 Closed and SW2-4 Open = 0° Wrist
Angle
SW2-3 Open and SW2-4 Closed = +90° Wrist
Angle
SW2-3 Closed and SW2-4 Closed = -90°
Wrist Angle
