sl3 inline reGulator
PurGe PoPPet assemblY
adJuster screW
8.
macroline fittinG
adJuster toP
reGulator seal
3
#011 nbr 70
inline reGulator
bottom
#016 nbr70
#016 nbr70
inline reGulator
Piston
inline reGulator
inline reGulator
inline reGulator
#011 nbr70
#008 nbr70
1
The Inline Regulator mounting threads on the Geo2
and SL3 are NOT compatible with older style regulator
threads (Ego 10 and older).
ONLY use the SL3 Geo2 Spring with the GEO2.
2
If the Purge Poppet Assembly is removed for
3
maintenance ensure is it re-installed correctly, failure to
do so may seriously damage the Geo2 solenoid.
sPrinG
2
toP
1
sWiVel
