PLANET ECLIPSE GEO2 Operator's Manual page 59

(continued)
Using a 5/64" hex key, unscrew and remove the back-Check
Assembly from the manifold (see fiGure 13.7)
Check Assembly comprises of three parts; the back-Check
ball, the back-Check Spring and the back-Check Cap
if the back-Check ball or Spring is deformed
fiGure 13.8).
or damaged replace as necessary using authentic Geo2
Spares.
rebuild the back-Check Assembly by placing the back-
Check ball into hole in the manifold and then attach the
back-Check Spring to the end of the back-Check Cap as
shown in . holding the manifold on its end,
fiGure 13.9
insert the connected Spring and Cap into their designated
hole in the manifold (see fiGure 13.10)
key screw the back-Check Cap back into the manifold to
hold the contents of the back-Check Assembly in place
(see fiGure 13.11) .
1
Using an appropriately sized Phillips head screwdriver,
remove the Spool Pack retaining screw from the manifold
and using a pair of needle nosed pliers
(see fiGure 13.12)
remove the Spool Pack from the manifold
13.13) .
1 If any of the components of the Back-Check assembly are
damaged or not installed correctly they will prevent the marker
from operating correctly.
. The back-
(see
. Using a 5/64 hex
(see fiGure
fiG 13.7 fiG 13.8
fiG 13.10
fiG 13.9
fiG 13.12 fiG 13.12
fiG 13.11 fiG 13.13
