PLANET ECLIPSE GEO2 Operator's Manual page 48

cleaninG tHe inline
reGulator
WarninG: de-Gas Your marKer, discHarGinG anY
stored Gas in a safe direction, and remoVe tHe
barrel, loader, air sYstem and anY Paintballs to
maKe tHe marKer easier and safer to WorK on.
Disconnect the macroline hosing from your inline
regulator allowing it to be unscrewed from the Front
regulator Mount (FrM)
o-ring at the top of the threads on the FrM for damage.
replace and re-lubricate as necessary
Turn the inline regulator upside down and carefully
unscrew the bottom section from the top section
fiGure 10.2
Tip both the Piston and Spring out of the top of the inline
regulator
insert a 1/8" hex key into the Adjuster Screw in the bottom
section of the inline regulator, turn the Adjuster Screw
clockwise through the top of the inline regulator bottom
(see fiGure 10.4)
bottom when it will no longer turn upwards.
Thoroughly clean the 011 Nbr70 o-rings that sit on the
outside of the Adjuster Assembly, then re-lubricate with
Eclipse Grease
If any o-rings are damaged then replace them. Extra o-rings are
1
available in parts kits available at
www.planeteclipse.com
The adjuster screw can only be removed by turning it upwards
2
through the bottom section of the Inline Regulator. The regulator
will be damaged if the adjuster screw is removed incorrectly.
48.
(see fiGure 10.1)
.1
).
).
(see fiGure 10.3
, and pull out of the inline regulator
(see oVerleaf fiGure 10.5)
. inspect the
(see
2
.
1
fiG 10.1
fiG 10.2
fiG 10.3
fiG 10.4
