adVanced inline
reGulator maintenance
WarninG: de-Gas Your marKer, discHarGinG anY
stored Gas in a safe direction, and remoVe tHe
barrel, loader, air sYstem and anY Paintballs to
maKe tHe marKer easier and safer to WorK on.
This procedure is only required if your are fixing a
supercharging Sl3 inline regulator (common symptoms
of supercharging are a very high velocity first shot and/or
large variances in shot to shot consistency.)
Place 3/32" hex key through the Adjuster Top
10.11) , then insert a 1/8" hex key into the bottom of the
Adjuster Screw and carefully turn it counter- clockwise until
the two parts begin to unscrew freely
with your fingers fully unscrew the two parts taking care
not to lose any of the internal components
.
10.13)
inside the Adjuster Screw you will find a regulator Seal,
Purge Poppet and Spring (Purge Poppet Assembly)
fiGure 10.14)
turning it over if one side appears excessively worn or
damaged or replace if necessary. inspect and clean the
Purge Poppet or replace if necessary.
Place the Purge Poppet and attached Spring in the central
hole in the regulator Seal, then insert these parts into the
Adjuster Screw
with the regulator Seal, Purge valve and Spring installed
back into the Adjuster Screw, replace the Adjuster Top
fiGure 10.16)
1/8" and 3/32" hex keys
'CLEANING THE SL3 INLINE REGULATOR'
re-assemble the Sl3 inline regulator.
1 If the Purge Poppet Assembly is removed for maintenance ensure
is it re-installed correctly, failure to do so may seriously damage
the Geo2 solenoid.
50.
(see fiGure 10.12)
(see fiGure
. inspect and clean the regulator Seal,
1
.
(see fiGure 10.15)
. Screw the two parts tightly together using
. refer to the
(see fiGure 10.12)
section on page 48 to
(see fiGure
.
(see
(see
fiG 10.11 fiG 10.12
fiG 10.13 fiG 10.14
fiG 10.15 fiG 10.16
