PLANET ECLIPSE GEO2 Operator's Manual page 74

screW
74.
QtY descriPtion
PCb SCrEw (3), bEAriNG CArriEr SCrEw (2)
5
( M2.5 x5 CAP hEAD SOCKET)
SOlENOiD SCrEw (2)
2
( M2.5 x12 CAP hEAD SOCKET)
rUbbEr GriP SCrEw (6), bbSS COvErS SCrEw (2)
8
( 6-32UNC x5/16 COUNTErSUNK SOCKET)
ShOrT FEED NECK SCrEw
1
( 1 x10-32UNF x1/2 CAP hEAD SOCKET)
1 ClAMPiNG FEED SPrOCKET
(CUSTOM MANUFACTUrED)
MiCrO-SwiTCh SCrEw
1
( 6-32 UNC x1/2 SOCKET SET SCrEw)
TriGGEr PiN rETAiNiNG SCrEw
1
( 6-32 UNC x1/8 SOCKET SET SCrEw)
TriGGEr lOCKiNG SCrEw
4
( 6-32 UNC x3/16 SOCKET SET SCrEw)
OOPS SCrEw
2
( 10-32 UNF x1/2 SOCKET SET SCrEw)
ShOrT FrAME SCrEw
1
( 10-32 UNF x3/8 SOCKET bUTTON hEAD)
lONG FrAME SCrEw
1
( 10-32 UNF x3/4 SOCKET bUTTON hEAD)
bODy PlUG
1
( CUSTOM MANUFACTUrED)
PrOP ShAFT rETAiNiNG SCrEw
1
( CUSTOM MANUFACTUrED)
