indeX
Actual rate of Fire......27
Adjuster Screw.........8
Adjuster Top........8
Advanced Trigger Filter Setup......40
ALARM......31, 45
Air System......17-18
Anti Double ball.................72 – 73
AUTO OFF......30, 42
AUX OUT......30, 42
AUx OUT indicator......23 - 24
BACK......28 - 31
back-Check Assembly............10, 72 – 73
BACKLIGHT......30, 41
basic Trigger Filter Set-up......40
battery......6, 14, 72 – 73
battery level indicator......23, 26
bearing Carrier Assembly......72 – 73
bearing Carrier Screw..............74
blanking Plug.......6
BLU LEvEL......30, 42
body......6, 72 – 73
body Plug...........72 – 74
bolt......9, 72 – 73
bolt bumper O-ring...............72 - 73
bolt Front O-ring............72 – 73
bolt rear O-ring..........72 - 73
bolt System.......6, 9, 52 - 54
break beam Sensor System (bbSS)......16, 46 - 47
break beam Sensor System indicator......23 - 24
BS OFF ROF......28, 35
BS ON ROF......28, 35
Can.......9, 72 – 73
Can External O-rings...............72 – 73
Can internal O-ring...............72 – 73
CANCEL......28 – 29
Clamping Feed Sprocket Screw.................72 – 74
Clamping Feed Swivel................72 – 73
Clamping Feed Tube............72 – 73
Clamping Feed Tube Screw.............72 – 73
Clamping lever......6
Circuit board......6, 15
DBL CLICK......31, 42
DEBOUNCE ......29, 39
Display Option..........23
Display window.................72 – 73
78.
DWELL......29, 38
E-Portal.......65
EMPTY......29, 39
EXIT......31
Expansion board.........65
Eye Cover......6
Eye Cover Screw......6, 74
FACTORY......28
Feedneck......6, 19
FILTER......21, 38
FIRE MODE.....28, 35
Frame......55 – 57, 72 – 73
Frame Screw........6
Front bumper..........9
Front Frame Screw...............72 – 74
Front Stop Trigger Screw......20
FSD COMP......29, 38
FSD DELAY......29, 38
FULL......30, 39
GAME......31, 45
Game Timer......26, 31
Gasket and Filter.........10
GAUGE......31, 44
GAUGE MAX......31, 44
GRN LEvEL......30, 42
HARDWARE......40
inline Purge Control valve...............72 – 73
inline regulator Adjuster Screw......50, 72 – 73
inline regulator Assembly......6, 48 - 49
inline regulator bottom......8, 72 – 73
inline regulator Piston......8, 72 – 73
inline regulator Spring......8, 72 – 73
inline regulator Swivel......8, 72 – 73
inline regulator Top......8, 72 – 73
KICK-IN......29, 37
LOAD......28, 34
loader......19
lock indicator......23, 26
LINEAR......29
Macroline Elbow......6, 18, 72 – 73
Macroline Fitting........8
Macroline hose......18, 72 – 73
Magnet return Strength Screw......20
Manifold...............10
Main Menu......28 – 31, 33
Menu System......27, 31
Menu Tree......28-31
Micro-switch Activation Screw......21, 72 – 74
